Mean Well ODLC-45-700DA Power Supply 45W 700mA, DALI
The ODLC-45 is a 45W Mean Well DIN rail power converter with a 111mm profile (input range: 90~295VAC, operating temperature: -40~+80℃).
Key Features
- ✓ 111mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 90~295VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+80℃
- ✓ Protections: Short circuit
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: (type”HL”) UL8750 BIS IS15885( for ODLC-45-700,1050,700DA,1050DA only), EAC TP TC 004,IP67
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesODLC Series
-
Power Rating44.8 Watt
-
Output Voltage64 Volt
-
Rated Current0.7 Ampere
-
Input Voltage90V~295V
-
No of Output1
-
Dimming ControlDALI
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Current
-
Operating Temperature-20°C~85°C
-
Warranty3 Year
-
Length4.37 in
-
Width3.03 in
-
Height1.12 in
-
Weight0.93 lb
::specification::
Frequently Asked Questions
Can the ODLC-45-700DA be used in a DALI-controlled LED downlight?
Yes, if the downlight's LED module requires 700mA constant current and operates within the 38-64V CC range. The driver delivers up to 44.8W, so the load must remain inside that output rating. Because this is the DA version, it is the appropriate series option when DALI control is needed.
Is this driver suitable for a 700mA signage module or small LED array?
It can be used for signage modules or small LED arrays that are built for 700mA constant current operation. The output voltage range is 38-64V, and the exact number of LEDs depends on each LED's forward voltage. This is not a constant voltage power supply.
Can I use the ODLC-45-700DA for medium-voltage architectural LED modules?
Yes, when the module is specified for 700mA constant current and its operating voltage stays between 38V and 64V. With a 44.8W rating, it is intended for loads up to that level. That makes it a fit for medium-voltage LED engines rather than lower-current, higher-voltage arrays.
How should I size LEDs for this constant current driver?
Start with the required drive current: the LED load must need 700mA constant current. Then confirm that the total forward voltage of the LEDs is within 38-64V; the number of LEDs depends on each LED's forward voltage, so there is no universal LED count. If your lighting product is specified for constant voltage, choose a constant voltage supply instead.
What is the environmental suitability of the ODLC-45-700DA?
This model is rated IP67 waterproof, so it is designed for use where that ingress protection level is required. Its operating temperature range is -20°C to +85°C, which supports demanding ambient conditions within that band. The finished luminaire or enclosure should be rated accordingly as well.
