Mean Well ODLV-65A-12 Power Supply 65W 12V (Auxiliary DC output)
The ODLV-65A is a 65W Mean Well DIN rail power converter with a 121mm profile (input range: 180~295VAC, operating temperature: -40~+80℃).
Key Features
- ✓ 121mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 180~295VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+80℃
- ✓ Protections: Short circuit
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: (type”HL”) UL8750 BIS IS15885( for ODLV-65-12,24,48 only), EAC TP TC 004,IP67
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesODLV Series
-
Power Rating50.4 Watt
-
Output Voltage12 Volt
-
Rated Current4.2 Ampere
-
Input Voltage180V~295V
-
No of Output1
-
Dimming Control0-10V,10V PWM,Auxiliary DC Output
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~85°C
-
Warranty3 Year
-
Length4.76 in
-
Width3.03 in
-
Height1.12 in
-
Weight0.95 lb
::specification::
Frequently Asked Questions
Can I use the ODLV-65A-12 for 12V LED strip lighting around signs or display borders?
Yes, if the strip is a 12V constant-voltage product and the total load stays within 50.4W. This model outputs 12V at 4.2A and is suitable for wet or outdoor locations because it is IP67 waterproof. Check the strip's rated power per meter before choosing total length.
Is this a good power supply for 12V LED modules in outdoor signage?
It can be used with 12V constant-voltage LED modules as long as the combined load does not exceed 50.4W. The IP67 rating supports outdoor and wet-location use, and the operating temperature range is -20°C to +85°C. Make sure the modules themselves are also 12V constant voltage.
Can the ODLV-65A-12 run 12V accent lighting for landscape or low-voltage decorative fixtures?
It can support 12V constant-voltage decorative lighting loads up to 50.4W. Because it is IP67 waterproof, it is suited to outdoor or damp applications where a sealed driver is needed. Verify the fixture voltage and total wattage before use.
How many meters of 12V LED strip can this driver power?
Use the formula: maximum strip length = 50.4W divided by the strip's watts per meter. This driver's output ceiling is 50.4W total at 12V and 4.2A. Check your strip rated power per meter and keep the full connected load at or below 50.4W.
Is the ODLV-65A-12 suitable for outdoor and temperature-exposed installations?
Yes, the driver is rated IP67 waterproof for wet and outdoor locations. It is specified for an operating temperature range of -20°C to +85°C, so it can be used where conditions stay inside that range. Environmental suitability of the attached 12V lighting still needs to be confirmed separately.
