Mean Well RS-35-3.3 Power Supply 35W 3.3V
The RS-35 is a 35W Mean Well DIN rail power converter with a 99mm profile (input range: 125~373VDC, operating temperature: -25~+70°C).
Key Features
- ✓ 99mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 125~373VDC
- ✓ Cooling by free air convection
- ✓ Wide operating temperature: -25~+70°C
- ✓ Protections: Short circuit / Overload / Over voltage
- ✓ Safety approvals: UL62368 TUV EN62368-1, EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesRS Series
-
Power Rating35 Watt
-
Output Voltage3.3 Volt
-
Rated Current7 Ampere
-
Input Voltage88V~264V
-
No of Output1
-
Standards MetBSMI,CB,CE,CQC,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-25°C~70°C
-
Warranty3 Year
-
Length3.9 in
-
Width3.23 in
-
Height1.42 in
-
Weight0.66 lb
::specification::
Frequently Asked Questions
Can I use the RS-35-3.3 to power 3.3V embedded boards or logic-level electronics?
Yes, if the equipment requires a constant 3.3V DC source and the total load stays within 35W and 7A. This makes it relevant for embedded boards, logic rails, and other low-voltage electronics designed around 3.3V.
Is the RS-35-3.3 suitable for FPGA, controller, or processor-based industrial electronics?
It can be used where processor, controller, or FPGA-based electronics need a regulated 3.3V DC input and draw no more than 7A. The wide 88-264VAC input is useful when the finished equipment may be installed in different regions.
Can this model support a 3.3V test bench or embedded development fixture?
Yes, for development fixtures or test benches built around 3.3V DC loads up to 35W. Its compact 99.0 × 82.0 × 36.0 mm footprint also makes it easier to place in compact electronics assemblies.
Is the RS-35-3.3 appropriate for harsh temperature conditions?
The operating temperature range is -25°C to +70°C, and the unit is specified to withstand 5G vibration. No IP rating is listed, so temperature tolerance is strong, but it should still be used in protected indoor or enclosed environments.
How does the RS-35-3.3 compare with the other 35W RS outputs?
The 35W RS family includes RS-35-3.3 at 3.3V and 7A, RS-35-5 at 5V and 7A, RS-35-12 at 12V and 3A, RS-35-15 at 15V and 2.4A, RS-35-24 at 24V and 1.5A, and RS-35-48 at 48V and 0.8A. RS-35-3.3 is the lowest-voltage option in that group while remaining in the same 35W class.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other RS-35 Models
5 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well RS-35-5 Power Supply 35W 5V | 35W | 5V | 7A | Indoor | $15.59 | View |
| Mean Well RS-35-48 Power Supply 35W 48V | 35W | 48V | 0.8A | Indoor | $15.69 | View |
| Mean Well RS-35-24 Power Supply 35W 24V | 35W | 24V | 1.5A | Indoor | $15.59 | View |
| Mean Well RS-35-15 Power Supply 35W 15V | 35W | 15V | 2.4A | Indoor | $15.59 | View |
| Mean Well RS-35-12 Power Supply 35W 12V | 35W | 12V | 3A | Indoor | $15.59 | View |
