Mean Well RS-35-24 Power Supply 35W 24V
The RS-35 is a 35W Mean Well DIN rail power converter with a 99mm profile (input range: 125~373VDC, operating temperature: -25~+70°C).
Key Features
- ✓ 99mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 125~373VDC
- ✓ Cooling by free air convection
- ✓ Wide operating temperature: -25~+70°C
- ✓ Protections: Short circuit / Overload / Over voltage
- ✓ Safety approvals: UL62368 TUV EN62368-1, EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesRS Series
-
Power Rating35 Watt
-
Output Voltage24 Volt
-
Rated Current1.5 Ampere
-
Input Voltage88V~264V
-
No of Output1
-
Standards MetBSMI,CB,CCC,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-25°C~70°C
-
Warranty3 Year
-
Length3.9 in
-
Width3.23 in
-
Height1.42 in
-
Weight0.66 lb
::specification::
Frequently Asked Questions
Can I use the RS-35-24 for a small PLC, sensor group, or 24V automation circuit?
Yes, if the connected 24V DC automation load stays within 35W and 1.5A. That makes it suitable for lighter 24V control circuits, small sensor groups, or compact automation assemblies.
Is the RS-35-24 suitable for industrial control cabinets that use 24V DC?
It is a practical choice for protected control cabinets where the equipment requires constant 24V DC and the load does not exceed 1.5A. The compact 99.0 × 82.0 × 36.0 mm size also helps in tighter enclosures.
Can this 24V model power embedded or industrial communications hardware?
It can power embedded or industrial communications hardware that is rated for a constant 24V DC input and remains within 35W. The 88-264VAC input range supports deployment in a wide range of AC-powered facilities.
Is the RS-35-24 for indoor use only?
The published specs show an operating range of -25°C to +70°C, but no IP rating is given. Without an IP rating, it is better treated as a supply for indoor panels or other protected enclosures rather than exposed outdoor use.
How does RS-35-24 compare with other 35W outputs in the RS series?
The 35W RS variants are RS-35-3.3 at 3.3V and 7A, RS-35-5 at 5V and 7A, RS-35-12 at 12V and 3A, RS-35-15 at 15V and 2.4A, RS-35-24 at 24V and 1.5A, and RS-35-48 at 48V and 0.8A. RS-35-24 keeps the same 35W class while providing a 24V output with lower current than the lower-voltage versions.
