Mean Well RS-35-12 Power Supply 35W 12V
The RS-35 is a 35W Mean Well DIN rail power converter with a 99mm profile (input range: 125~373VDC, operating temperature: -25~+70°C).
Key Features
- ✓ 99mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 125~373VDC
- ✓ Cooling by free air convection
- ✓ Wide operating temperature: -25~+70°C
- ✓ Protections: Short circuit / Overload / Over voltage
- ✓ Safety approvals: UL62368 TUV EN62368-1, EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesRS Series
-
Power Rating35 Watt
-
Output Voltage12 Volt
-
Rated Current3 Ampere
-
Input Voltage88V~264V
-
No of Output1
-
Standards MetBSMI,CB,CCC,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-25°C~70°C
-
Warranty3 Year
-
Length3.9 in
-
Width3.23 in
-
Height1.42 in
-
Weight0.66 lb
::specification::
Frequently Asked Questions
Can I use the RS-35-12 for a 12V industrial control panel or automation enclosure?
Yes, if the panel components need a constant 12V DC supply and the total load stays within 35W and 3A. Its compact 99.0 × 82.0 × 36.0 mm size also helps in smaller control enclosures.
Is the RS-35-12 suitable for powering 12V embedded systems or industrial electronics?
It is a fit for embedded or industrial electronics that require regulated 12V DC and draw no more than 3A from a 35W supply. The wide 88-264VAC input is useful when the equipment may be deployed across different AC mains environments.
Can this 12V power supply run small 12V HMI accessories, relays, or control devices?
It can support small 12V control devices, relay assemblies, or HMI-related accessories when their combined demand remains at or below 35W and 3A. This model is constant voltage, so it is intended for equipment designed for a 12V DC source.
Is the RS-35-12 intended for indoor or outdoor use?
The provided specs list an operating temperature range of -25°C to +70°C, but no IP rating is provided. Without an IP rating, it is better suited to protected indoor or enclosed equipment use rather than exposed outdoor conditions.
How does the RS-35-12 compare with other 35W Mean Well RS models?
Within the 35W RS group, the options are RS-35-3.3 at 3.3V and 7A, RS-35-5 at 5V and 7A, RS-35-12 at 12V and 3A, RS-35-15 at 15V and 2.4A, RS-35-24 at 24V and 1.5A, and RS-35-48 at 48V and 0.8A. The main difference between them is the output voltage and matching current rating at the same 35W power level.
