Mean Well RS-35-48 Power Supply 35W 48V
The RS-35 is a 35W Mean Well DIN rail power converter with a 99mm profile (input range: 125~373VDC, operating temperature: -25~+70°C).
Key Features
- ✓ 99mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 125~373VDC
- ✓ Cooling by free air convection
- ✓ Wide operating temperature: -25~+70°C
- ✓ Protections: Short circuit / Overload / Over voltage
- ✓ Safety approvals: UL62368 TUV EN62368-1, EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesRS Series
-
Power Rating35 Watt
-
Output Voltage48 Volt
-
Rated Current0.8 Ampere
-
Input Voltage88V~267V
-
No of Output1
-
Standards MetBSMI,CB,CCC,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-25°C~70°C
-
Warranty3 Year
-
Length3.9 in
-
Width3.23 in
-
Height1.42 in
-
Weight0.66 lb
::specification::
Frequently Asked Questions
Can I use the RS-35-48 for 48V telecom or industrial communications equipment?
Yes, if the equipment is designed for a constant 48V DC input and draws no more than 35W and 0.8A. That makes it relevant for lighter-duty telecom or industrial communications hardware built around a 48V DC bus.
Is the RS-35-48 suitable for 48V control devices in automation systems?
It can be used for small 48V control devices or subsystems when the total demand stays within 0.8A at 48V. The supply is constant voltage, so it should only be used with equipment intended for a regulated 48V DC source.
Can this power supply support compact embedded or IT hardware that runs on 48V DC?
It is suitable for compact embedded or IT hardware that accepts 48V DC input and remains within the 35W output limit. Its 99.0 × 82.0 × 36.0 mm size is also useful where mounting space is constrained.
Is the RS-35-48 rated for outdoor use?
The provided specs show an operating temperature range of -25°C to +70°C, but no IP rating is listed. Without an IP rating, it is better considered for indoor cabinets or other protected enclosures instead of exposed outdoor locations.
How does RS-35-48 compare with the other 35W RS models?
The 35W RS lineup includes RS-35-3.3 at 3.3V and 7A, RS-35-5 at 5V and 7A, RS-35-12 at 12V and 3A, RS-35-15 at 15V and 2.4A, RS-35-24 at 24V and 1.5A, and RS-35-48 at 48V and 0.8A. RS-35-48 is the highest-voltage version in that 35W group and therefore carries the lowest current rating.
