Mean Well RSP-1500-24 Power Supply 1512W 24V
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well RSP-1500-24 Power Supply 1512W 24V
The RSP-1500 is a 1500W Mean Well power converter (input range: 90~264VAC).
Key Features
- ✓ Input voltage range: 90~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Remote ON/OFF control
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesRSP Series
-
Power Rating1512 Watt
-
Output Voltage24 Volt
-
Rated Current63 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Standards MetBSMI,CB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~70°C
-
Warranty5 Year
-
Length10.94 in
-
Width5 in
-
Height3.29 in
-
Weight6.61 lb
::specification::
Frequently Asked Questions
What large-scale 24V systems can the RSP-1500-24 power?
The RSP-1500-24 delivers 24V at 63A (1512W) and is suited for large 24V DC bus applications including industrial robot control panels, conveyor drive systems, large-scale PLC installations, and facility-wide 24V sensor/actuator networks requiring over 1kW of power. The 90–264VAC input is universally compatible.
Does the RSP-1500-24 support parallel operation for redundancy?
Yes. The RSP-1500-24 supports active current sharing (3+1), allowing up to three units in parallel for 189A at 24V combined, plus a fourth unit in N+1 hot standby. This provides both increased capacity and fault tolerance for critical 24V systems.
How does the RSP-1500-24 compare to the RSP-1000-24?
The RSP-1000-24 delivers 24V/40A/960W in a 295.0 × 127.0 × 41.0 mm chassis with a -20°C to +60°C operating range. The RSP-1500-24 delivers 24V/63A/1512W in a 278.0 × 127.0 × 83.5 mm chassis with a -20°C to +70°C range. The RSP-1500-24 provides 57% more current and a higher temperature ceiling.
What is the operating temperature ceiling for the RSP-1500-24?
The RSP-1500-24 operates from -20°C to +70°C ambient, giving it a 10°C higher upper temperature limit than the RSP-1000-24. No IP rating is specified; the unit must be housed in an appropriately rated enclosure for the installation environment.
What is the efficiency of the RSP-1500-24?
The RSP-1500-24 achieves up to 91% efficiency with built-in active PFC. At the 1512W rated output, input power is approximately 1662W and heat dissipation is approximately 150W, which must be managed by the enclosure cooling system.
