Mean Well RSP-200-48 Power Supply 200W 24V
The RSP-200 is a 200W Mean Well DIN rail power converter with a 215mm profile (input range: 88~264VAC).
Key Features
- ✓ 215mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 88~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: AS/NZS 60950.1
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesRSP Series
-
Power Rating200 Watt
-
Output Voltage48 Volt
-
Rated Current4.2 Ampere
-
Input Voltage88V~264V
-
No of Output1
-
Standards MetBSMI,CB,CCC,CE,EAC,RCM,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length8.46 in
-
Width4.53 in
-
Height1.18 in
-
Weight1.59 lb
::specification::
Frequently Asked Questions
What 48V applications can the RSP-200-48 serve at 200W?
The RSP-200-48 delivers 48V at 4.2A (200W) and is suited for 48V DC bus segments in telecom cabinets, small PoE switch auxiliary rails, 48V motor drive logic supplies, and industrial network infrastructure. The 88–264VAC input supports worldwide AC mains.
How does the RSP-200-48 compare to the RSP-150-48 and RSP-100-48?
The RSP-100-48 delivers 48V at 2.1A (100.8W, 179mm). The RSP-150-48 delivers 48V at 3.2A (153.6W, 199mm). The RSP-200-48 delivers 48V at 4.2A (200W, 215mm). All are 1U low-profile. The RSP-200-48 provides the highest current and wattage in the 100–200W 48V range.
Is the RSP-200-48 appropriate for a 48V telecom cabinet environment?
The RSP-200-48 operates from -30°C to +70°C and holds no IP rating. For a telecom cabinet, the unit must be installed in an enclosure that protects against dust and any moisture. Its -30°C to +70°C range covers all standard indoor telecom cabinet temperature requirements.
What certifications does the RSP-200-48 hold?
The RSP-200-48 carries BSMI, CB, CCC, CE, EAC, c_rcm, TÜV, and UL certifications, including CCC (China) and c_rcm (Australia/NZ), providing broad global coverage.
What are all RSP-200 variants at 24V and above for comparison?
Higher-voltage RSP-200 variants: RSP-200-24 (200W/24V/8.4A), RSP-200-27 (200W/27V/7.5A), RSP-200-36 (200.16W/36V/5.56A), RSP-200-48 (200W/48V/4.2A). All use the same 215.0 × 115.0 × 30.0 mm chassis.
