Mean Well SCW20C-15 DC-DC Converter - 20W 36~75V DC in 15V out
The SCW20C is a 20W Mean Well power converter (input range: 9~18Vdc, operating temperature: -40~+105℃).
Key Features
- ✓ Input voltage range: 9~18Vdc
- ✓ 1.5KVDC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+105℃
- ✓ Protections: Short circuit / Overload
- ✓ Remote ON/OFF control
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSCW Series
-
Power Rating20 Watt
-
Output Voltage15 Volt
-
Rated Current1.33 Ampere
-
Input Voltage0.015V~0.479V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~80°C
-
Warranty3 Year
-
Length1.25 in
-
Width0.8 in
-
Height0.48 in
-
Weight0.04 lb
::specification::
Frequently Asked Questions
Can I use the SCW20C-15 for a 15V industrial control or instrumentation load?
Yes, this unit delivers a constant 15V output with up to 1.33A output current. Its 20W power rating and 36~75V DC input range make it suitable for 15V loads that fit within those electrical limits.
Is the SCW20C-15 appropriate for embedded analog or control circuits that need 15V DC?
It can be a fit where a regulated 15V rail is required and the total demand stays within 1.33A and 20W. That output profile is relevant for embedded and automation electronics using a 15V constant-voltage supply.
Can this converter step down a 36~75V DC bus for 15V auxiliary electronics?
Yes, converting from 36~75V DC input to 15V output is the core function of this model. It is intended for auxiliary 15V electronics as long as the load remains within the 1.33A and 20W ratings.
What are the output differences across the SCW20C-05, SCW20C-12, and SCW20C-15?
They are all 20W converters in the same series, but each has a different output voltage and current rating. SCW20C-05 is 5V at 4A, SCW20C-12 is 12V at 1.67A, and SCW20C-15 is 15V at 1.33A.
Is the SCW20C-15 rated for outdoor conditions or wide ambient temperatures?
The specs list an operating temperature range of -40°C to +80°C, so it is specified for wide-temperature operation. No IP rating appears in the provided data, so outdoor exposure suitability is not established by these specs.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other SCW20 Models
8 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well SCW20C-12 DC-DC Converter - 20W 36~75V DC in 12V out | 20W | 12V | 1.66A | Indoor | $25.89 | View |
| Mean Well SCW20C-05 DC-DC Converter - 20W 36~75V DC in 5V out | 20W | 5V | 4A | Indoor | $23.87 | View |
| Mean Well SCW20B-15 DC-DC Converter - 20W 18~36V DC in 15V out | 20W | 15V | 1.33A | Indoor | $23.81 | View |
| Mean Well SCW20B-12 DC-DC Converter - 20W 18~36V DC in 12V out | 20W | 12V | 1.66A | Indoor | $23.81 | View |
| Mean Well SCW20B-05 DC-DC Converter - 20W 18~36V DC in 5V out | 20W | 5V | 4A | Indoor | $23.81 | View |
| Mean Well SCW20A-15 DC-DC Converter - 20W 9~18V DC in 15V out | 20W | 15V | 1.33A | Indoor | $23.87 | View |
| Mean Well SCW20A-12 DC-DC Converter - 20W 9~18V DC in 12V out | 20W | 12V | 1.66A | Indoor | $23.87 | View |
| Mean Well SCW20A-05 DC-DC Converter - 20W 9~18V DC in 5V out | 20W | 5V | 4A | Indoor | $23.87 | View |
