Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well SCW20A-12 DC-DC Converter - 20W 9~18V DC in 12V out

Name: Mean Well SCW20A-12 DC-DC Converter - 20W 9~18V DC in 12V out
Brand: Mean Well
SKU: SCW20A-12
Price: 23.87 USD
Availability: InStock

$23.87 USD

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

Description

Features

DIP24 package with industry-standard pinout

2:1 wide input range

Operating temperature range -40 ~ +80°C

No minimum load required

Comply to BS EN/EN55032 radiated Class A without additional components

High efficiency up to 89%

Protections: Short circuit (Continuous) / Overload / Input under voltage

1.5KVDC I/O isolation

Remote ON/OFF control

2 years warranty

General Specification

Voltage set point accuracy	±2% (max.)
Line regulation	±0.5% (max.)
Load regulation	±0.5%
Overload protection	120 ~ 190% rated output power
Efficiency	88% (typical)
Short circuit protection	Protection type: Continuous, automatic recovery
I/O isolation voltage	1000VDC (min.)
I/O isolation resistance	I/P-O/P:100M Ohms / 500VDC / 25°C / 70% RH
Isolation capacitance	1200pF (max.)
Working temperature	-40 ~ +80°C (Refer to "Derating Curve")
Storage temperature	+110°C max
EMC	Compliance to EN55022 class B, EN61000-4-2,3,4,5,6,8, FCC part15 class B
Temp. Coefficient	±0.03% /°C (0 ~ 85°C)
Dimension (LxWxH) (mm)	31.8 x 20.3 x 12.2mm (1.25 x 0.8 x 0.48 inch)
Case material	Five-sided shield metal case

Specifications

Brand

Mean Well
Series

SCW Series
Power Rating

20 Watt
Output Voltage

12 Volt
Rated Current

1.66 Ampere
Input Voltage

0.03V~1.938V
No of Output

1
Dimming Control

None
Standards Met

CE,EAC
Operation Mode

Constant Voltage
Operating Temperature

-40°C~80°C
Warranty

3 Year
Length

1.25 in
Width

0.8 in
Height

0.48 in
Weight

0.04 lb

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Features

DIP24 package with industry-standard pinout

2:1 wide input range

Operating temperature range -40 ~ +80°C

No minimum load required

Comply to BS EN/EN55032 radiated Class A without additional components

High efficiency up to 89%

Protections: Short circuit (Continuous) / Overload / Input under voltage

1.5KVDC I/O isolation

Remote ON/OFF control

2 years warranty

General Specification

Voltage set point accuracy

±2% (max.)

Line regulation

±0.5% (max.)

Load regulation

±0.5%

Overload protection

120 ~ 190% rated output power

Efficiency

88% (typical)

Short circuit protection

Protection type: Continuous, automatic recovery

I/O isolation voltage

1000VDC (min.)

I/O isolation resistance

I/P-O/P:100M Ohms / 500VDC / 25°C / 70% RH

Isolation capacitance

1200pF (max.)

Working temperature

-40 ~ +80°C (Refer to "Derating Curve")

Storage temperature

+110°C max

EMC

Compliance to EN55022 class B, EN61000-4-2,3,4,5,6,8, FCC part15 class B

Temp. Coefficient

±0.03% /°C (0 ~ 85°C)

Dimension (LxWxH) (mm)

31.8 x 20.3 x 12.2mm (1.25 x 0.8 x 0.48 inch)

Case material

Five-sided shield metal case
