Mean Well SCW20C-12 DC-DC Converter - 20W 36~75V DC in 12V out 1.666A
The SCW20C is a 20W Mean Well power converter (input range: 9~18Vdc, operating temperature: -40~+105℃).
Key Features
- ✓ Input voltage range: 9~18Vdc
- ✓ 1.5KVDC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+105℃
- ✓ Protections: Short circuit / Overload
- ✓ Remote ON/OFF control
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSCW Series
-
Power Rating20 Watt
-
Output Voltage12 Volt
-
Rated Current1.66 Ampere
-
Input Voltage0.015V~0.479V
-
No of Output1
-
Dimming ControlNon Dimmable
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~80°C
-
Warranty3 Year
-
Length1.25 in
-
Width0.8 in
-
Height0.48 in
-
Weight0.04 lb
::specification::
Frequently Asked Questions
Can I use the SCW20C-12 to run a 12V automation device from a 36~75V DC source?
Yes, this converter provides constant-voltage 12V output with up to 1.67A output current. With a 20W rating and 36~75V DC input range, it is suited to 12V automation loads that stay within those limits.
Is the SCW20C-12 suitable for 12V relays, control modules, or interface hardware in industrial equipment?
It can be used for 12V industrial control hardware when the load fits within 12V, 1.67A, and 20W. This makes it a practical match for regulated 12V auxiliary electronics in embedded and automation systems.
Can this model power 12V monitoring or communication electronics on a higher-voltage DC bus?
It is intended to step a 36~75V DC input down to a constant 12V output. As long as the connected electronics do not exceed 1.67A output current or 20W, it is an appropriate 12V DC conversion option.
How does the SCW20C-12 compare with the other SCW20C output options?
The SCW20C-12 shares the same 20W series platform as the other versions but changes the output rating. The sibling options are 5V at 4A for SCW20C-05, 12V at 1.67A for SCW20C-12, and 15V at 1.33A for SCW20C-15.
Can the SCW20C-12 be used in cold or hot industrial environments?
The published operating temperature range is -40°C to +80°C, so it is specified for both low and high ambient conditions within that range. No IP rating is listed, so the provided specs do not confirm outdoor or washdown use.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other SCW20 Models
8 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well SCW20C-15 DC-DC Converter - 20W 36~75V DC in 15V out 1.333A | 20W | 15V | 1.33A | Indoor | $23.87 | View |
| Mean Well SCW20C-05 DC-DC Converter - 20W 36~75V DC in 5V out 4A | 20W | 5V | 4A | Indoor | $23.87 | View |
| Mean Well SCW20B-15 DC-DC Converter - 20W 18~36V DC in 15V out 1.333A | 20W | 15V | 1.33A | Indoor | $23.81 | View |
| Mean Well SCW20B-12 DC-DC Converter - 20W 18~36V DC in 12V out 1.666A | 20W | 12V | 1.66A | Indoor | $23.81 | View |
| Mean Well SCW20B-05 DC-DC Converter - 20W 18~36V DC in 5V out 4A | 20W | 5V | 4A | Indoor | $23.81 | View |
| Mean Well SCW20A-15 DC-DC Converter - 20W 9~18V DC in 15V out 1.333A | 20W | 15V | 1.33A | Indoor | $23.87 | View |
| Mean Well SCW20A-12 DC-DC Converter - 20W 9~18V DC in 12V out 1.666A | 20W | 12V | 1.66A | Indoor | $23.87 | View |
| Mean Well SCW20A-05 DC-DC Converter - 20W 9~18V DC in 5V out 4A | 20W | 5V | 4A | Indoor | $23.87 | View |
