Mean Well SCW20B-15 DC-DC Converter - 20W 18~36V DC in 15V out

SKU:
SCW20B-15

$23.81 USD
Shipping calculated at checkout.
|

Your order will be processed within 24 hours

Description

Features

DIP24 package with industry-standard pinout
2:1 wide input range
Operating temperature range -40 ~ +80°C
No minimum load required
Comply to BS EN/EN55032 radiated Class A without additional components
High efficiency up to 89%
Protections: Short circuit (Continuous) / Overload / Input under voltage
1.5KVDC I/O isolation
Remote ON/OFF control
2 years warranty

General Specification

Voltage set point accuracy ±2% (max.)
Line regulation ±0.5% (max.)
Load regulation ±0.5%
Overload protection 120 ~ 190% rated output power
Efficiency 88% (typical)
Short circuit protection Protection type: Continuous, automatic recovery
I/O isolation voltage 1000VDC (min.)
I/O isolation resistance I/P-O/P:100M Ohms / 500VDC / 25°C / 70% RH
Isolation capacitance 1200pF (max.)
Working temperature -40 ~ +80°C (Refer to "Derating Curve")
Storage temperature +110°C max
EMC Compliance to EN55022 class B, EN61000-4-2,3,4,5,6,8, FCC part15 class B
Temp. Coefficient ±0.03% /°C (0 ~ 85°C)
Dimension (LxWxH) (mm) 31.8 x 20.3 x 12.2mm (1.25 x 0.8 x 0.48 inch)
Case material Five-sided shield metal case

Specifications

  • Brand
    Mean Well
  • Series
    SCW Series
  • Power Rating
    20 Watt
  • Output Voltage
    15 Volt
  • Rated Current
    1.33 Ampere
  • Input Voltage
    0.025V~0.957V
  • No of Output
    1
  • Dimming Control
    None
  • Standards Met
    CE,EAC
  • Operation Mode
    Constant Voltage
  • Operating Temperature
    -40°C~80°C
  • Warranty
    3 Year
  • Length
    1.25 in
  • Width
    0.8 in
  • Height
    0.48 in
  • Weight
    0.04 lb

File Downloads

::specification::
