Mean Well APC-35-350 Power Supply 35W 350mA
Description
Description
The APC-35 is a 35W Mean Well. power converter. and an input range of 28~100V.
Key Features
- ✓ Input voltage range: 28~100V
- ✓ 3KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~70℃
- ✓ Protections: Over voltage
- ✓ Safety approvals: UL8750 (only for APC-35-700&1050), CSA-C22.2 No. 250.0-13 (only for APC-35-1050), IP42
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesAPC Series
-
Power Rating35 Watt
-
Output Voltage100 Volt
-
Rated Current0.35 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetBSMI,CE,cUL,EAC
-
Operation ModeConstant Current
-
Operating Temperature-30°C~70°C
-
Warranty2 Year
-
Length3.31 in
-
Width2.24 in
-
Height1.16 in
-
Weight0.4 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What kinds of LED applications is the APC-35-350 designed for?
The Mean Well APC-35-350 is designed for constant-current LED lighting and moving sign applications that need a 350mA drive current with a higher power class than the smaller APC-25-350. With 35W rated power, it is suited to 350mA LED loads that need more output capability.
Is the APC-35-350 a good fit for 350mA LED loads?
Yes. The APC-35-350 is a constant-current LED driver rated at 350mA, so it should be matched to LED loads designed for that current level. The load also needs to stay within the driver's voltage and power capability.
Can the APC-35-350 be used for longer or higher-voltage 350mA LED strings than the APC-25-350?
Yes. Compared with the APC-25-350, the APC-35-350 offers a higher 35W power class and a higher 100V output rating, which makes it a better fit when a 350mA LED load needs more output margin. The actual LED load still needs to remain within the driver's published ratings.
Will the APC-35-350 run on standard AC mains supplies?
Yes. The specified input range is 90-264VAC, so the APC-35-350 can operate from common 120V and 240V mains systems within that range. That helps standardize the same driver across multiple indoor lighting environments.
Is the APC-35-350 intended for direct outdoor installation?
No. The APC-35-350 has an IP30 design, which means it is better suited to indoor use or protected enclosures rather than direct exposure to weather. Its listed working temperature is -30°C to +70°C, but ingress protection remains limited.
How does the APC-35-350 compare with other APC-35 drivers?
The APC-35-350 provides 35W at 350mA, while the APC-35-500, APC-35-700, and APC-35-1050 are designed for 500mA, 700mA, and 1050mA LED loads respectively. The main selection rule is to match the constant-current rating to the LED load rather than choosing only by wattage.
Other APC-35 Models
3 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well APC-35-500 Power Supply 35W 500mA | 35W | 70V | 0.5A | Indoor | $16.33 | View |
| Mean Well APC-35-700 Power Supply 35W 700mA | 35W | 50V | 0.7A | Indoor | $6.35 | View |
| Mean Well APC-35-1050 Power Supply 35W 1050mA | 34.7W | 33V | 1.05A | Indoor | $13.91 | View |
