Mean Well DPB09B-05 DC-DC Converter - 9W - 18~36V in ±5V out
Description
Description
The DPB09B is a 9W Mean Well power converter (input range: 9~18Vdc).
Key Features
- ✓ Input voltage range: 9~18Vdc
- ✓ 1.5KVDC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload
- ✓ Remote ON/OFF control
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesDPB Series
-
Power Rating9 Watt
-
Output Voltage5 Volt
-
Rated Current0.8 Ampere
-
Input Voltage18V~36V
-
No of Output2
-
Dimming ControlNone
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length0.98 in
-
Width0.44 in
-
Height0.38 in
-
Weight0.01 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the DPB09B-05 in industrial electronics that run from an 18-36VAC source and need dual 5V rails?
Yes. This model is designed for 18-36VAC input and provides constant-voltage ±5V output. It is rated for 9W with 800A output current, making it suitable for low-voltage industrial electronics within that input range.
Is the DPB09B-05 suitable for embedded control or communications boards in higher-voltage AC systems?
It can be a fit when the available source is 18-36VAC and the load requires constant-voltage ±5V output. The converter provides 9W in a compact 24.9 × 11.2 × 9.6 mm package.
Can this converter be used for compact automation modules that need low-voltage dual-rail power?
Yes. Its size is 24.9 × 11.2 × 9.6 mm and its weight is 0.005 kg, which supports use in compact automation assemblies. The output is constant-voltage ±5V at 9W from an 18-36VAC input.
Is the DPB09B-05 appropriate for hot or cold industrial environments?
The specified operating temperature range is -40°C to +90°C, so it is suitable for wide-temperature operation in protected equipment. No IP rating is provided, so it should be used in enclosed or indoor environments rather than exposed outdoor locations.
How does the DPB09B-05 differ from the other DPB09B models?
The DPB09B series shares the same 9W rating and 18-36VAC input range across the listed models. The DPB09B-05 outputs 5V at 800A, the DPB09B-12 outputs 12V at 375A, and the DPB09B-15 outputs 15V at 300A.
Other DPB09 Models
8 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well DPB09C-15 DC-DC Converter - 9W - 36~75V in ±15V out | 9W | 15V | 0.3A | Indoor | $15.50 | View |
| Mean Well DPB09C-12 DC-DC Converter - 9W - 36~75V in ±12V out | 9W | 12V | 0.37A | Indoor | $15.50 | View |
| Mean Well DPB09C-05 DC-DC Converter - 9W - 36~75V in ±5V out | 9W | 5V | 0.8A | Indoor | $15.50 | View |
| Mean Well DPB09B-15 DC-DC Converter - 9W - 18~36V in ±15V out | 9W | 15V | 0.3A | Indoor | $15.59 | View |
| Mean Well DPB09B-12 DC-DC Converter - 9W - 18~36V in ±12V out | 9W | 12V | 0.37A | Indoor | $15.50 | View |
| Mean Well DPB09A-15 DC-DC Converter - 9W - 9~18V in ±15V out | 9W | 15V | 0.3A | Indoor | $15.50 | View |
| Mean Well DPB09A-12 DC-DC Converter - 9W - 9~18V in ±12V out | 9W | 12V | 0.37A | Indoor | $15.50 | View |
| Mean Well DPB09A-05 DC-DC Converter - 9W - 9~18V in ±5V out | 9W | 5V | 0.8A | Indoor | $15.50 | View |
