Mean Well DPB09C-15 DC-DC Converter - 9W - 36~75V in ±15V out
Description
Description
The DPB09C is a 9W Mean Well power converter (input range: 9~18Vdc).
Key Features
- ✓ Input voltage range: 9~18Vdc
- ✓ 1.5KVDC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload
- ✓ Remote ON/OFF control
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesDPB Series
-
Power Rating9 Watt
-
Output Voltage15 Volt
-
Rated Current0.3 Ampere
-
Input Voltage36V~75V
-
No of Output2
-
Dimming ControlNone
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length0.98 in
-
Width0.44 in
-
Height0.38 in
-
Weight0.01 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the DPB09C-15 for instrumentation or control boards that require ±15V rails?
Yes, this model provides ±15V output from a 36-75V input range in a constant-voltage design. Its 9W rating makes it suitable for low-power instrumentation, control, and analog support circuits rather than larger 15V loads.
Is the DPB09C-15 suitable for embedded analog electronics on higher-voltage DC buses?
It can be a fit for embedded analog electronics that need regulated ±15V output and receive input within 36-75V. Because the unit is rated for 9W, it is better matched to small auxiliary sections than to power-dense subsystems.
Can this converter be used in automation or measurement modules with tight space limits?
Yes, the 24.9 × 11.2 × 9.6 mm package and 0.005 kg weight support compact module designs. The electrical fit is strongest where the application needs ±15V at low power within the 9W limit.
Is the DPB09C-15 intended for outdoor service or mainly protected enclosures?
The published temperature range is -40°C to +90°C, which supports demanding thermal conditions. No IP rating is listed, so the available specifications do not identify it as an outdoor-rated product.
How does the DPB09C-15 differ from the other models in the DPB09C family?
All three listed DPB09C variants are 9W units. DPB09C-05 is 5V and 800A, DPB09C-12 is 12V and 375A, and DPB09C-15 is 15V and 300A.
Other DPB09 Models
8 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well DPB09C-12 DC-DC Converter - 9W - 36~75V in ±12V out | 9W | 12V | 0.37A | Indoor | $15.50 | View |
| Mean Well DPB09C-05 DC-DC Converter - 9W - 36~75V in ±5V out | 9W | 5V | 0.8A | Indoor | $15.50 | View |
| Mean Well DPB09B-15 DC-DC Converter - 9W - 18~36V in ±15V out | 9W | 15V | 0.3A | Indoor | $15.59 | View |
| Mean Well DPB09B-12 DC-DC Converter - 9W - 18~36V in ±12V out | 9W | 12V | 0.37A | Indoor | $15.50 | View |
| Mean Well DPB09B-05 DC-DC Converter - 9W - 18~36V in ±5V out | 9W | 5V | 0.8A | Indoor | $15.50 | View |
| Mean Well DPB09A-15 DC-DC Converter - 9W - 9~18V in ±15V out | 9W | 15V | 0.3A | Indoor | $15.50 | View |
| Mean Well DPB09A-12 DC-DC Converter - 9W - 9~18V in ±12V out | 9W | 12V | 0.37A | Indoor | $15.50 | View |
| Mean Well DPB09A-05 DC-DC Converter - 9W - 9~18V in ±5V out | 9W | 5V | 0.8A | Indoor | $15.50 | View |
