Mean Well ICL-28R AC Inrush Current Limiter
Description
Description
The ICL is a Mean Well power converter.
Key Features
- ✓ Protections: Overload / Over voltage
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesICL
-
Rated Current28 Ampere
-
Input Voltage85V~264V
-
No of Output1
-
Standards MetCE,EAC
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length3.54 in
-
Width2.15 in
-
Height2.07 in
-
Weight0.35 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What does the Mean Well ICL-28R do?
The ICL-28R is an AC inrush current limiter designed to reduce high startup current on compatible AC-powered equipment. For this model, it provides 48A inrush current limiting and supports 28A continuous current operation.
What input range is supported by the ICL-28R?
This model is rated for 180 to 264VAC input. It is intended for AC applications within that voltage range and has an AC input power rating of 6440VA.
How is the ICL-28R different from a basic NTC inrush limiter?
The ICL-28R uses an integrated bypass relay rather than relying on a simple NTC-only design. That makes it a stronger fit for buyers looking for a dedicated DIN rail inrush limiting solution with continuous current capability up to 28A.
Is the ICL-28R suitable for industrial environments?
Yes, this model is built for demanding industrial use cases with a wide operating temperature range of -30°C to +70°C. It also supports operation at altitudes up to 5000 meters and includes internal thermal protection.
What kind of protection and compliance does the ICL-28R include?
The ICL-28R includes an internal thermal fuse intended to protect against overload and fire risk. It is approved to LVD BS EN/EN62368-1 and meets EMC standards including EN55032 Class B and EN61000-4 series requirements listed for this model.
Is the ICL-28R compatible with DIN rail control panels?
Yes, the ICL-28R is designed for DIN rail mounting on TS-35/7.5 or TS-35/15 rail formats. Its compact 52.5 x 90 x 54.5 mm housing helps it fit into space-conscious panel layouts.
