Mean Well LPH-18-24 Power Supply 18W 24V

slim plastic case, economical, IP67
SKU:
LPH-18-24

$8.46 USD
Shipping calculated at checkout.
|

Your order will be processed within 24 hours

Description

Features

180~264VAC input only
Fully encapsulated with IP67 level
Protections: Short circuit / Overload / Over voltage / Over temperature
Constant voltage design (C.V. mode)
Class 2 power unit / Pass LPS
Isolation class II, no F.G.
Cooling by free air convection
100% full load burn-in test
Low cost, high reliability
Suitable for LED-based decorative/architectural lighting, LED stage and theater lighting, and LED electronic displays
2 years warranty


General Specification

AC input voltage range 180~264VAC
AC inrush current Cold start 50A at 230VAC
Overload Range >105%
Protection Type Hiccup mode, auto-recovery
Over voltage protection 115%~135% rated output voltage
Withstand voltage I/P-O/P: 3kVAC
Working temperature -30~+70°C
Vibration 10~500Hz, 2G 10 minutes /1 cycle, period for 60 minutes each along X, Y, Z axes
Safety standards TUV EN60950-1, EN61347-1, EN61347-2-13 approved for LPH-18
EMC standards EN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11
Connection Input UL rated,18AWGx2C (30cm)
Connection Output UL rated,18AWGx2C (30cm)
Dimension (LxWxH)(mm) 140x 30x 22

Specifications

  • Brand
    Mean Well
  • Series
    LP Series
  • Power Rating
    18 Watt
  • Output Voltage
    24 Volt
  • Rated Current
    0.75 Ampere
  • Input Voltage
    180V~264V
  • No of Output
    1
  • Dimming Control
    None
  • Standards Met
    CE,EAC,TUV
  • Operation Mode
    Constant Voltage
  • Operating Temperature
    -30°C~70°C
  • Warranty
    2 Year
  • Length
    5.51 in
  • Width
    1.18 in
  • Height
    0.79 in
  • Weight
    0.39 lb
