Mean Well MHB100-48S12 DC-DC Converter - 100W - 36~75V in 12V out
Description
Description
The MHB100 is a 100W Mean Well power converter (input range: 18~36VDC).
Key Features
- ✓ Input voltage range: 18~36VDC
- ✓ Protections: Short circuit / Over voltage / Over temperature / Under voltage
- ✓ Remote ON/OFF control
- ✓ Safety approvals: UL60950-1 EAC TP TC 004
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesMHB Series
-
Power Rating100 Watt
-
Output Voltage12 Volt
-
Rated Current8.3 Ampere
-
Input Voltage36V~75V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,EAC,EMC,RCM,TUV
-
Operation ModeConstant Voltage
-
Operating Temperature-55°C~105°C
-
Warranty3 Year
-
Length2.4 in
-
Width2.28 in
-
Height0.5 in
-
Weight0.21 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the MHB100-48S12 for 12V industrial monitoring or control hardware on a 36-75VAC source?
Yes, this converter accepts 36-75VAC input and provides a constant 12V output. With 8.3A output current and 100W total power, it fits 12V control, monitoring, and embedded equipment that stays within those limits.
Is this model suitable for powering 12V embedded systems in higher-voltage equipment?
It is suitable when the embedded system requires constant 12V and does not exceed 8.3A or 100W. The 36-75VAC input range makes it better matched to higher-input systems than the 24S input versions.
Can the MHB100-48S12 support 12V automation accessories and control electronics?
Yes, for 12V constant-voltage loads with a combined draw up to 8.3A and 100W. Its compact 61.0 x 57.9 x 12.7 mm package can also help in space-constrained industrial assemblies.
Does this converter work in very cold or hot environments, and is it outdoor-rated?
The specified operating temperature range is -55°C to +105°C, which supports use across a wide temperature span. No IP rating is provided in the listed specs, so direct outdoor exposure or water resistance is not established by this product data.
What are the main differences between the MHB100-48S12 and its sibling models?
The sibling list shows six 100W variants split across two input families. The 24S group includes 5V 20A, 12V 8.3A, and 24V 4.17A models, and the 48S group includes 5V 20A, 12V 8.3A, and 24V 4.17A models, with this unit being the 48S 12V 8.3A version.
Other MHB100 Models
5 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well MHB100-48S24 DC-DC Converter - 100W - 36~75V in 24V out | 100W | 24V | 4.17A | Indoor | $82.90 | View |
| Mean Well MHB100-48S05 DC-DC Converter - 100W - 36~75V in 5V out | 100W | 5V | 20A | Indoor | $82.90 | View |
| Mean Well MHB100-24S24 DC-DC Converter - 100W - 18~36V in 24V out | 100W | 24V | 4.17A | Indoor | $82.90 | View |
| Mean Well MHB100-24S12 DC-DC Converter - 100W - 18~36V in 12V out | 100W | 12V | 8.3A | Indoor | $78.63 | View |
| Mean Well MHB100-24S05 DC-DC Converter - 100W - 18~36V in 5V out | 100W | 5V | 20A | Indoor | $82.90 | View |
