Mean Well NTS-400P-224 True Sine Wave DC-AC Inverter 400W 230V out 24V in
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well NTS-400P-224 True Sine Wave DC-AC Inverter 400W 230V out ...
The NTS-400P is a 400W Mean Well power converter (input range: 10~16.5Vdc).
Key Features
- ✓ Input voltage range: 10~16.5Vdc
- ✓ Protections: Short circuit / Overload / Over voltage / Over temperature / Reverse polarity
- ✓ Remote ON/OFF control
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesNTS Series
-
Power Rating400 Watt
-
Output Voltage230 Volt
-
Input Voltage20V~33V
-
No of Output1
-
Standards MetCB,CE,cUL,E13,FCC
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~70°C
-
Warranty3 Year
-
Length7.32 in
-
Width3.96 in
-
Height1.26 in
-
Weight1.65 lb
::specification::
Frequently Asked Questions
What is the Mean Well NTS-400P-224 designed for?
The NTS-400P-224 is a 400W true sine wave DC-AC inverter that converts 24V DC input power to 230V AC output. It is suited to applications that need utility-style AC power from a DC battery source, including commercial, industrial, and mobile power systems.
Does this inverter provide a true sine wave output?
Yes. This model delivers a true sine wave AC output with total harmonic distortion below 3%, which makes it a better fit for sensitive electronics than modified sine wave inverters. Its nominal output for this version is 230V AC.
What input voltage does the NTS-400P-224 require?
This model is built for 24V DC input systems. It is also described as suitable for lead-acid or lithium-ion battery applications, making it relevant for buyers standardizing on a 24V battery platform.
Can this inverter handle startup surges above its rated power?
Yes. The NTS-400P-224 has a continuous power rating of 400W and supports surge power up to 800W. That can help with loads that briefly draw more power at startup than during normal operation.
Is this inverter suitable for demanding environmental conditions?
It is designed for a wide operating temperature range of -20°C to +70°C, with reference to the output derating curve at higher temperatures. The unit also includes conformal coating, which can be valuable in tougher operating environments.
What protection features are included in the NTS-400P-224?
This inverter includes protection for short circuit, overload, and over voltage conditions. It also has battery over-discharge protection through low voltage disconnect, helping protect the connected DC power source.
How does this model differ from basic or modified sine wave inverters?
The main difference is its true sine wave output, which more closely matches standard AC mains power. The NTS-400P-224 also offers selectable AC output voltage and frequency by DIP switch, remote power on-off capability, and Tx/Rx status monitoring support.
