Mean Well ODLV-65-36 Power Supply 65W 36V, Dimmable
The ODLV-65 is a 65W Mean Well DIN rail power converter with a 121mm profile (input range: 180~295VAC, operating temperature: -40~+80℃).
Key Features
- ✓ 121mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 180~295VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+80℃
- ✓ Protections: Short circuit
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: (type”HL”) UL8750 BIS IS15885( for ODLV-65-12,24,48 only), EAC TP TC 004,IP67
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesODLV Series
-
Power Rating64.8 Watt
-
Output Voltage36 Volt
-
Rated Current1.8 Ampere
-
Input Voltage180V~295V
-
No of Output1
-
Dimming Control0-10V,10V PWM
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~85°C
-
Warranty3 Year
-
Length4.76 in
-
Width3.03 in
-
Height1.12 in
-
Weight0.95 lb
::specification::
Frequently Asked Questions
Can I use the ODLV-65-36 for 36V LED strip lighting on an outdoor sign?
Yes, if the LED strip is a 36V constant-voltage product and the total load stays within 64.8W. This driver is IP67 waterproof, so it is intended for wet or outdoor locations. Check the strip's rated power per meter before sizing the run.
Is this power supply suitable for 36V architectural linear lighting?
It can be used for 36V constant-voltage linear lighting where the fixture load does not exceed 64.8W at 1.8A. The IP67 enclosure supports outdoor or damp-area lighting, and the operating temperature range is -20°C to +85°C. Confirm the fixture itself is rated for 36V constant voltage.
Can this driver power 36V LED ribbon for building outline or facade accents?
Yes, for 36V constant-voltage LED ribbon with a combined load up to 64.8W. That makes it relevant for exterior accent lighting, signage borders, or similar 36V strip applications where IP67 protection is needed. Verify the ribbon's total watt draw before selecting the driver.
How much 36V LED strip can the ODLV-65-36 run?
Use the strip length formula: maximum length = 64.8W divided by the strip's watts per meter. For example, the driver's limit is 64.8W total at 36V and 1.8A. Check your strip rated power per meter and keep the full run at or below that 64.8W maximum.
Is the ODLV-65-36 okay for wet locations and temperature swings?
This model is rated IP67 waterproof, so it is designed for outdoor and wet-location use. Its operating temperature range is -20°C to +85°C, which covers both cold and hot environments within that stated range. The connected lighting load still needs its own matching environmental rating.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other ODLV-65 Models
4 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well ODLV-65-60 Power Supply 65W 60V, Dimmable | 64.8W | 60V | 1.08A | IP67 | $27.23 | View |
| Mean Well ODLV-65-48 Power Supply 65W 48V, Dimmable | 64.8W | 48V | 1.35A | IP67 | $27.23 | View |
| Mean Well ODLV-65-24 Power Supply 65W 24V, Dimmable | 57.6W | 24V | 2.4A | IP67 | $27.23 | View |
| Mean Well ODLV-65-12 Power Supply 65W 12V, Dimmable | 50.4W | 12V | 4.2A | IP67 | $23.04 | View |
