Mean Well ODLV-65-60 Power Supply 65W 60V, Dimmable
The ODLV-65 is a 65W Mean Well DIN rail power converter with a 121mm profile (input range: 180~295VAC, operating temperature: -40~+80℃).
Key Features
- ✓ 121mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 180~295VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+80℃
- ✓ Protections: Short circuit
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: (type”HL”) UL8750 BIS IS15885( for ODLV-65-12,24,48 only), EAC TP TC 004,IP67
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesODLV Series
-
Power Rating64.8 Watt
-
Output Voltage60 Volt
-
Rated Current1.08 Ampere
-
Input Voltage180V~295V
-
No of Output1
-
Dimming Control0-10V,10V PWM
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~85°C
-
Warranty3 Year
-
Length4.76 in
-
Width3.03 in
-
Height1.12 in
-
Weight0.95 lb
::specification::
Frequently Asked Questions
Can I use the ODLV-65-60 for 60V LED strip lighting on outdoor architectural projects?
Yes, if the LED strip or linear load is a 60V constant-voltage product and the total demand is 64.8W or less. This model outputs 60V at 1.08A and has an IP67 waterproof rating for wet or outdoor locations. Confirm the fixture is specifically rated for 60V constant voltage.
Is this driver suitable for 60V signage or perimeter lighting systems?
It can be used with 60V constant-voltage signage or perimeter lighting loads up to 64.8W. The IP67 enclosure supports outdoor exposure, and the operating temperature range is -20°C to +85°C. Load voltage and operating mode must match the driver exactly.
Can the ODLV-65-60 power 60V LED ribbon for facade accent lighting?
Yes, for 60V constant-voltage LED ribbon where the combined load does not exceed 64.8W. This makes it relevant for exterior accent lighting and similar high-voltage strip applications that require a waterproof driver. Check the ribbon's rated power per meter before sizing the run.
How much 60V LED strip can this 64.8W driver support?
Calculate the maximum run as 64.8W divided by the strip's watts per meter. The driver's output limit is 64.8W total at 60V and 1.08A. Check your strip rated power per meter and keep the total strip load at or below 64.8W.
Can the ODLV-65-60 be used in rain, washdown, or exposed outdoor conditions?
Its IP67 waterproof rating means the driver is intended for wet and outdoor environments. It is also specified for operation from -20°C to +85°C, so temperature suitability should be judged against that stated range. The rest of the lighting system still needs to be rated for the same environment.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other ODLV-65 Models
4 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well ODLV-65-48 Power Supply 65W 48V, Dimmable | 64.8W | 48V | 1.35A | IP67 | $27.23 | View |
| Mean Well ODLV-65-36 Power Supply 65W 36V, Dimmable | 64.8W | 36V | 1.8A | IP67 | $27.23 | View |
| Mean Well ODLV-65-24 Power Supply 65W 24V, Dimmable | 57.6W | 24V | 2.4A | IP67 | $27.23 | View |
| Mean Well ODLV-65-12 Power Supply 65W 12V, Dimmable | 50.4W | 12V | 4.2A | IP67 | $23.04 | View |
