Mean Well PCD-40-1400B Power Supply 40W 1400mA
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well PCD-40-1400B Power Supply 40W 1400mA
The PCD-40 is a 40W Mean Well power converter (input range: 70~108V, operating temperature: -30~+50℃).
Key Features
- ✓ Input voltage range: 70~108V
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~+50℃
- ✓ Protections: Short circuit / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: ENEC EN61347-1, EN61347-2-13 independent, EN62384, IP42
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesPCD Series
-
Power Rating40.6 Watt
-
Output Voltage29 Volt
-
Rated Current1.4 Ampere
-
Input Voltage180V~295V
-
No of Output1
-
Dimming ControlAC Phase Cut Dimming
-
Standards MetCB,CE,EAC,ENEC
-
Operation ModeConstant Current
-
Operating Temperature-30°C~50°C
-
Warranty3 Year
-
Length5.04 in
-
Width2.36 in
-
Height1.24 in
-
Weight0.51 lb
::specification::
Frequently Asked Questions
Can I use the PCD-40-1400B for a 1400mA LED downlight?
Yes, if the downlight is designed for constant current operation at 1400mA and its LED load falls within the 17-29V constant current range. This driver provides constant current, not constant voltage, so it needs a fixture built for CC input. Its rated output power is 40.6W.
Is the PCD-40-1400B a good fit for compact signage LED modules?
It can be used for signage LED modules when the module assembly requires 1400mA constant current and operates within 17-29V. That makes it more suitable for constant current signage assemblies than for constant voltage sign modules. It is also TRIAC dimmable for systems that use TRIAC dimming.
Can this model power a small LED array with a lower forward voltage than 30V?
Yes, this driver is built for constant current LED arrays that operate from 17V to 29V at 1400mA. That makes it relevant for compact arrays that need higher current and a lower voltage range than some other 40W siblings. The load also needs to stay within the 40.6W power rating.
What should I check before pairing the PCD-40-1400B with an LED load?
The LED load should require 1400mA constant current, and its total forward voltage should be within the 17-29V constant current range. The number of LEDs depends on each LED's forward voltage, so there is no single fixed LED count for this driver. If the load needs a constant voltage supply, this model is not compatible.
Is the PCD-40-1400B intended for indoor operation only?
Its IP42 plastic casing points to indoor use or other locations where limited ingress protection is acceptable. It is not described as a sealed outdoor driver. The operating temperature range is -30°C to +50°C.
How does the PCD-40-1400B compare with nearby 1400mA models in the PCD series?
The listed 1400mA siblings are PCD-16-1400A and PCD-16-1400B at 8-12V and 16.8W, PCD-25-1400A and PCD-25-1400B at 12-18V and 25.2W, PCD-40-1400B at 17-29V and 40.6W, and PCD-60-1400B at 25-43V and 60.2W. In the same 40W class, the current alternatives are PCD-40-1050B at 22-38V and 39.9W, PCD-40-1750B at 13-23V and 40.25W, PCD-40-700B at 34-57V and 39.9W, PCD-40-500B at 45-80V and 40W, and PCD-40-350B at 70-108V and 37.8W. This places the PCD-40-1400B in the middle of the 1400mA range progression.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other PCD-40 Models
5 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well PCD-40-700B Power Supply 40W 700mA | 39.9W | 57V | 0.7A | Indoor | $22.55 | View |
| Mean Well PCD-40-500B Power Supply 40W 500mA | 40W | 80V | 0.5A | Indoor | $23.66 | View |
| Mean Well PCD-40-350B Power Supply 40W 350mA | 37.8W | 108V | 0.35A | Indoor | $22.55 | View |
| Mean Well PCD-40-1750B Power Supply 40W 1750mA | 40.25W | 23V | 1.75A | Indoor | $21.32 | View |
| Mean Well PCD-40-1050B Power Supply 40W 1050mA | 39.9W | 38V | 1.05A | Indoor | $25.78 | View |
