Mean Well RD-35A Power Supply 35W 5V 12V
Description
Description
The RD is a 125W Mean Well DIN rail power converter with a 99mm profile (input range: 176~264VAC, operating temperature: -25~+70°C).
Key Features
- ✓ 99mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 176~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ Cooling by free air convection
- ✓ Wide operating temperature: -25~+70°C
- ✓ Protections: Short circuit / Overload / Over voltage
- ✓ Safety approvals: UL62368- TUV EN62368-1, EAC TP TC 004
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesRD Series
-
Power Rating32 Watt
-
Output Voltage5 Volt
-
Rated Current4 Ampere
-
Input Voltage88V~264V
-
No of Output2
-
Standards MetCB,CE,EAC,RCM,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-25°C~70°C
-
Warranty3 Year
-
Length3.9 in
-
Width3.23 in
-
Height1.42 in
-
Weight0.66 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the RD-35A in a small controller that needs both 5V logic and 12V support power?
Yes. The RD-35A is a dual output constant voltage supply with 5V and 12V outputs. The listed 5V output current is 4A and total power is 32W, so it fits lower-power control or embedded systems that need both rails.
Is the RD-35A suitable for compact automation hardware with limited mounting space?
It is well suited to compact enclosures because the housing is 99.0 x 82.0 x 36.0 mm and weighs 0.3 kg. With 32W total power and a 5V output rated at 4A, it fits lighter-duty industrial or embedded equipment that needs a small dual output supply.
Can the RD-35A be used in industrial equipment that sees vibration or warm cabinet conditions?
Yes. The specifications list 5G vibration resistance and an operating range of -25°C to +70°C. Those ratings make it suitable for enclosed industrial and automation equipment where vibration and internal heat are part of normal operation.
Is the RD-35A appropriate for outdoor installations?
An IP rating is not listed for this model, so it should be considered an indoor power supply or one that must be installed inside a protective enclosure. The operating temperature range is -25°C to +70°C, but no outdoor ingress protection is specified.
How does the RD-35A compare with the other RD family models listed here?
The RD-35A is one of the smaller models at 32W with a listed 5V output current of 4A. Other specified siblings are RD-35B at 35W with 5V 2.2A, RD-3513 at 35.1W with 13.5V 1.3A, RD-50A at 54W with 5V 6A, RD-50B at 53.6W with 5V 4A, RD-65A at 66W with 5V 6A, RD-65B at 68W with 5V 4A, RD-85A and RD-85B at 88W with 5V 8A, RD-125A at 130.9W with 5V 7.7A, and RD-125B at 133.4W with 5V 4.6A.
