Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well RSP-200-27 Power Supply 200W 24V
The RSP-200 is a 200W Mean Well DIN rail power converter with a 215mm profile (input range: 88~264VAC).
Key Features
- ✓ 215mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 88~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: AS/NZS 60950.1
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesRSP Series
-
Power Rating200 Watt
-
Output Voltage27 Volt
-
Rated Current7.5 Ampere
-
Input Voltage88V~264V
-
No of Output1
-
Standards MetBSMI,CB,CCC,CE,EAC,RCM,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length8.46 in
-
Width4.53 in
-
Height1.18 in
-
Weight1.59 lb
::specification::
Frequently Asked Questions
What applications specify a 27V power supply of the RSP-200-27's rating?
The RSP-200-27 delivers 27V at 7.5A (200W) and is suited for 24V lead-acid battery charging systems requiring an elevated float voltage, certain industrial process control equipment with 27V bus specifications, and telecommunications infrastructure at 27V. The 88–264VAC input supports worldwide AC mains.
How does the RSP-200-27 compare to the RSP-200-24 and RSP-200-36?
The RSP-200-24 delivers 24V at 8.4A (200W). The RSP-200-27 delivers 27V at 7.5A (200W). The RSP-200-36 delivers 36V at 5.56A (200.16W). All share the 215.0 × 115.0 × 30.0 mm chassis and 88–264VAC input. As voltage increases, current decreases at approximately the same total wattage.
Is the RSP-200-27 suitable for industrial environments up to +70°C?
Yes. The RSP-200-27 is rated from -30°C to +70°C ambient, covering the full industrial temperature range for most applications. No IP ingress rating is provided; an appropriate enclosure is required for dusty or wet environments.
What certifications does the RSP-200-27 carry?
The RSP-200-27 holds BSMI, CB, CCC, CE, EAC, c_rcm, TÜV, and UL, covering Taiwan, China, Europe, Australia/NZ, North America, and EAC.
What are all RSP-200 voltage variants?
The RSP-200 series voltage options are: RSP-200-2.5 (100W/2.5V/40A), RSP-200-3.3 (132W/3.3V/40A), RSP-200-4 (160W/4V/40A), RSP-200-5 (200W/5V/40A), RSP-200-7.5 (200.25W/7.5V/26.7A), RSP-200-12 (200.4W/12V/16.7A), RSP-200-13.5 (201.15W/13.5V/14.9A), RSP-200-15 (201W/15V/13.4A), RSP-200-24 (200W/24V/8.4A), RSP-200-27 (200W/27V/7.5A), RSP-200-36 (200.16W/36V/5.56A), RSP-200-48 (200W/48V/4.2A). All share the 215.0 × 115.0 × 30.0 mm chassis and 88–264VAC input.
