Over 15 years experience of providing support of MEAN WELL Power Supplies
Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well XLG-320-48-ABV Power Supply 312W 48V 6.5A
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well XLG-320-48-ABV Power Supply 312W 48V 6.5A
Key Features
- ✓Wide input range 100~305V AC(Class I)
- ✓Full power output at 75~100% Constant power mode operation
- ✓Metal case with IP67, suitable for outdoor application
- ✓Surge protection with 6KV/4KV
- ✓3-in-1 Dimming (Dim-to-off and Isolation design)
- ✓Protection functions: OLP / SCP / OVP / OTP
- ✓Compliance to EN60335-1 household application
- ✓Lifetime >50,000 hrs
- ✓5 years warranty
-
BrandMean Well
-
SeriesXLG Series
-
Power Rating312 Watt
-
Output Voltage48 Volt
-
Rated Current6.5 Ampere
-
Input Voltage100V~305V
-
No of Output1
-
Dimming Control0-10V,10V PWM,Resistance
-
Standards MetCB,CCC,CE,EAC,ENEC,RCM,SELV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~85°C
-
Warranty5 Year
-
Length9.69 in
-
Width3.03 in
-
Height1.56 in
-
Weight3.2 lb
::specification::
Frequently Asked Questions
Can I use the XLG-320-48-ABV to power 48V LED strip lighting in an outdoor sign cabinet?
Yes. The XLG-320-48-ABV is rated IP67, meaning it is fully protected against dust ingress and temporary water immersion, making it suitable for outdoor and enclosed sign cabinet installations. It supplies 48V at up to 6.5A with a 312W capacity, which is appropriate for driving 48V LED strip runs in signage applications.
Can this power supply drive a long run of 48V LED strip for architectural lighting?
Yes. At 312W and 48V, this driver can support up to 312W of 48V LED strip load — for example, roughly 31 meters of 10W/m strip or 20.8 meters of 15W/m strip. Always check your strip's rated power per meter and derate to 80% of the driver's max load for continuous use. The flicker-free constant voltage output also suits high-visibility architectural installations.
Does the XLG-320-48-ABV support dimming for tunable or dimmable LED strip systems?
Yes. This unit includes a 3-in-1 dimming function supporting 1-10V, PWM, and resistance dimming methods. The output is specified as flicker-free CV dimming, which is suitable for photography studios, retail displays, or any application sensitive to flicker.
Is the XLG-320-48-ABV suitable for wet or outdoor environments?
Yes. The IP67 rating means this driver is dustproof and can withstand temporary immersion in up to 1 meter of water for 30 minutes. Its operating temperature range of -20°C to +85°C also covers most outdoor climates. It is appropriate for exterior architectural lighting, outdoor sign boxes, and covered wet-location LED installations.
Can I adjust the output voltage on the XLG-320-48-ABV to fine-tune strip brightness?
Yes. The output voltage is adjustable, allowing you to trim the 48V output within a range to compensate for cable voltage drop in longer runs or to optimize LED strip brightness. This is particularly useful in constant voltage LED strip systems where precise voltage delivery affects uniform brightness along the strip.
How does the XLG-320-48-ABV compare to other 320W XLG models?
The XLG-320 series includes constant current (CC) models at high voltages (H, L, M variants) and constant voltage (CV) models like this one and the XLG-320-V-A. The XLG-320-48-ABV provides 312W at 48V (CV) with dimming, while the XLG-320-V-A offers 312W at 24V (CC) without dimming, and the H/L/M variants use constant current at much higher voltages for series LED string applications.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other XLG-320 Models
4 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well XLG-320-V-A Power Supply 312W 24V or 216W 12V - Switchable Voltage | 312W | 24V | 13A | IP67 | $127.53 | View |
| Mean Well XLG-320-M-DA2 Power Supply 310.8W 2800mA - DALI2 Dimmable | 310.8W | 180V | 2.8A | IP67 | $134.52 | View |
| Mean Well XLG-320-L-DA2 Power Supply 315W 1400mA - DALI2 Dimmable | 315W | 340V | 1.4A | IP67 | $134.52 | View |
| Mean Well XLG-320-H-DA2 Power Supply 312W 5600mA - DALI2 Dimmable | 312W | 65V | 5.6A | IP67 | $134.52 | View |
