Mean Well XTR-960-48 Three Phase Din Rail Power Supply 960W 48V - Screw Terminal
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well XTR-960-48 Three Phase Din Rail Power Supply 960W 48V - S...
TheXTR-960series is a high-capacity 960W power supply, designed to deliver reliable power in challenging industrial settings. Its efficiency and advanced features make it ideal for large-scale applications requiring stable power and enhanced performance. The series supports parallel operation, ensuring scalability and flexibility in power distribution.
Key Features:
-
BrandMean Well
-
SeriesMean Well XTR Series
-
Power Rating960 Watt
-
Output Voltage48 Volt
-
Rated Current20 Ampere
-
Input Voltage320V~600V
-
No of Output1
-
Standards MetCB,CCC,CE,EAC,EN,KC
-
Operating Temperature-40°C~85°C
-
Warranty5 Year
-
Length5.2 in
-
Width3.78 in
-
Height4.93 in
-
Weight3.97 lb
::specification::
Frequently Asked Questions
What are the main output specs of the Mean Well XTR-960-48?
The XTR-960-48 is a 960W AC-DC DIN rail power supply with a 48V output. It is rated for 20A output current, making it suitable for higher-power industrial DC loads.
What input power range does the XTR-960-48 support?
This model supports a three-phase 320 to 600Vac wide input range. The product description also notes that dual-phase operation is possible.
What types of applications is the XTR-960-48 intended for?
The XTR-960-48 is designed for challenging industrial settings that require stable, high-capacity DC power. Its 960W rating and 48V output make it a fit for larger control panels, automation systems, and other industrial power distribution uses.
What operating temperature range does this power supply support?
The XTR-960-48 is specified for operation from -40°C to 85°C. That wide temperature range supports use in demanding industrial environments where ambient conditions may vary significantly.
Can the XTR-960-48 support scalable power systems?
Yes. The XTR-960 series supports parallel operation, which can help scale power capacity in suitable system designs.
When should a buyer choose the XTR-960-48 instead of a lower-wattage DIN rail power supply?
This model is appropriate when the load requires up to 960W at 48V and a rated current of 20A. For applications with substantially lower power demand, a lower-wattage DIN rail supply may be more appropriate.
What is the warranty period for the XTR-960-48?
The XTR-960-48 has a 5-year warranty period. This is useful for B2B buyers comparing expected service life and support coverage across industrial power supplies.
How much does the XTR-960-48 weigh?
The listed weight for the XTR-960-48 is 1.8 kg. This may be relevant for panel planning, shipping estimates, and equipment documentation.
