Can I use the LCM-60 for higher-power LED downlights?

Yes, this constant current driver is a stronger option for LED downlights that need more headroom, with a 60.3W rating and a 2-86V constant current range. It is a better fit for constant current downlights than constant voltage products because the driver regulates current rather than supplying a fixed DC voltage.

Is the LCM-60 suitable for larger LED signage modules or small LED arrays?

It can be suitable where the LED module or array is designed for constant current operation and the total load stays within 60.3W and the 2-86V CC range. That wider voltage range gives it more flexibility than the 40W versions for higher-voltage constant current loads.

Can this driver be used for dimmable architectural LED arrays?

Yes, it is relevant for dimmable constant current LED arrays because it includes built-in 3 in 1 dimming and a flicker-free design. The array still needs to match the selected current setting and remain within the 2-86V constant current window.

How do I check LED compatibility with the LCM-60?

Confirm that the LEDs require constant current drive and that their total forward voltage stays within the 2-86V constant current output range. The number of LEDs depends on each LED forward voltage, so the proper sizing method is total forward voltage, not a fixed LED count.

Is the LCM-60 suitable for broad temperature ranges?

Its operating temperature range is -30°C to +90°C, which supports use in demanding indoor lighting environments and enclosed luminaires. These specs do not provide an IP rating, so exposure to dust or water should be managed by the final enclosure.

1 5

Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well

Mean Well LCM-60 AC-DC Multi-Stage LED driver Constant Current

Name: Mean Well LCM-60 AC-DC Multi-Stage LED driver Constant Current
Brand: Mean Well
SKU: LCM-60
Price: 34.69 USD
Availability: InStock

selectable output current using dip switchflicker-freeClass II without FGbuilt-in 3 in 1 dimming

SKU LCM-60

$34.69 USD ~~$236.00~~

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

The LCM-60 is a 60.3W Mean Well AC-DC constant current LED driver (input: 180~295VAC, output: 102V, operating temperature: -30~+90°C).

Key Features

✓ Input voltage: 180~295VAC
✓ Output voltage (max): 102V
✓ Rated output current: 700mA
✓ Selectable output current via dip switch
✓ 3-in-1 dimming (0–10V / PWM / resistance)
✓ Flicker-free output
✓ Class II design — no earth connection required
✓ Operating temperature: -30~+90°C
✓ Safety certifications: BSI, CB, CCC, CE, EAC, ENEC, UL
✓ 3 year warranty

Brand

Mean Well
Series

LCM Series
Power Rating

60.3 Watt
Output Voltage

102 Volt
Rated Current

0.7 Ampere
Input Voltage

180V~295V
No of Output

6
Dimming Control

10V PWM,1-10V,Resistance
Standards Met

BSI,CB,CCC,CE,EAC,ENEC,UL
Operation Mode

Constant Current
Operating Temperature

-30°C~90°C
Warranty

3 Year
Length

4.86 in
Width

3.21 in
Height

0.91 in
Weight

0.53 lb

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	Voltage	Current	IP Rating	Price
Mean Well LCM-60U Power Supply 50W 500mA 600mA 700mA(default) 900mA 1050mA 1400mA - DALI and Push	50.4W	76V	0.7A	Indoor	$34.69	View
Mean Well LCM-40U Power Supply 35W 350mA 500mA 600mA 700mA(default) 900mA 1050mA - DALI and Push	35W	65V	0.7A	Indoor	$31.29	View
Mean Well LCM-60DA2 Power Supply 60W 500mA 600mA 700mA(default) 900mA 1050mA 1400mA - DALI2 and Push	6W	95V	0.9A	IP20	$42.48	View
Mean Well LCM-40DA2 Power Supply 40W 350mA 500mA 600mA 700mA(default) 900mA 1050mA - DALI2 and Push	40W	65V	0.6A	IP20	$39.71	View
Mean Well LCM-40 Power Supply 42W 350mA 500mA 600mA 700mA(default) 900mA 1050mA - Dimmable	42W	65V	0.7A	Indoor	$31.29	View
Mean Well LCM-25DA2 Power Supply 25W 350mA 500mA 600mA 700mA(default) 900mA 1050mA - DALI2 and Push	25W	41V	0.7A	IP20	$33.87	View
Mean Well LCM-25 Power Supply 25W 350mA 500mA 600mA 700mA(default) 900mA 1050mA - Dimmable	25.2W	41V	0.7A	Indoor	$25.80	View
