Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well DPRN01L-12 DC-DC Converter - 1W - 4.75~5.5V in ±12V out
The DPRN01L is a 1W Mean Well power converter (input range: 4.75~5.5Vdc).
Key Features
- ✓ Input voltage range: 4.75~5.5Vdc
- ✓ 1.5KVDC reinforced I/O isolation
- ✓ Protections: Short circuit
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesDPRN Series
-
Power Rating1 Watt
-
Output Voltage12 Volt
-
Rated Current0.04 Ampere
-
Input Voltage4.75V~5.5V
-
No of Output2
-
Dimming ControlNone
-
Standards MetCE,EMC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length0.77 in
-
Width0.4 in
-
Height0.28 in
-
Weight0.01 lb
::specification::
Frequently Asked Questions
Can I use the DPRN01L-12 to generate 12V rails from a 5V logic supply in embedded equipment?
Yes, this model is intended for a listed input range of 4.75-5.5V and provides a constant-voltage 12V output. Its 1W rating means it fits low-power embedded and interface circuits rather than heavier 12V loads.
Is the DPRN01L-12 suitable for isolated low-power sensor or measurement circuitry?
It can fit low-power sensor, measurement, or interface sections that need a 12V constant-voltage output from a 4.75-5.5V input. The 1W power rating and 0.04A output current keep it in the low-load category.
Would this converter work for compact IT or communications boards that start with a 5V rail?
It is a practical option when the system already provides 4.75-5.5V input and only needs a small 12V rail. The compact 19.6 x 10.14 x 7.1 mm package and 0.0025 kg weight support dense board layouts.
Can the DPRN01L-12 be used in automation electronics with limited space and low power demand?
Yes, for low-power automation subcircuits that need 12V output and stay within 1W. Its small 19.6 x 10.14 x 7.1 mm size suits compact modules and control boards.
What is the difference between the DPRN01L-12 and DPRN01L-15?
Both models are rated at 1W and share the same series format. The DPRN01L-12 provides 12V at 0.04A, while the DPRN01L-15 provides 15V at 0.03A.
Is the DPRN01L-12 appropriate for outdoor or extreme-temperature use?
Its specified operating temperature range is -40°C to +90°C, which supports operation across a broad temperature range. No IP rating is listed, so the published specifications do not identify it as outdoor-rated.
