Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well DPRN01L-15 DC-DC Converter - 1W - 4.75~5.5V in ±15V out

SKU:

DPRN01L-15

$5.35 USD

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

Description

Features

SIP6 package with industry-standard pinout

Wide operating temperature range -40~+90°C

Comply to BS EN/EN55032 radiated Class B without additional components

Low cost

Protection: Short circuit

1.5KVDC I/O isolation

3 years warranty

General Specification

Voltage accuracy	±3%
Vibration	10~500Hz, 2G 10min./1 cycle, the period for 60 min, each along the X, Y, and Z axes
Cooling	Free-air convection
Short circuit protection	SPRN01: Current limit protection 60 sec. max., DPRN01: 1 sec. max.
Working temperature	-40°C to +90°C
EMC	Compliance to EN55032 class B, EN61000-4-2,3,4,5,6,8
Temp. Coefficient	0.05% / ℃ (0 ~ 71℃)
Dimension (LxWxH) (mm)	19.67.110.14mm
Potting material	UL 94V-0 rated

Specifications

Brand

Mean Well
Series

DPRN Series
Power Rating

1 Watt
Output Voltage

15 Volt
Rated Current

0.03 Ampere
Input Voltage

4.75V~5.5V
No of Output

2
Dimming Control

None
Standards Met

CE,EMC
Operation Mode

Constant Voltage
Operating Temperature

-40°C~90°C
Warranty

3 Year
Length

0.77 in
Width

0.4 in
Height

0.28 in
Weight

0.01 lb

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can I use the DPRN01L-15 to create a 15V rail from a 5V source in embedded electronics?

Yes, it is specified for a 4.75-5.5V input range and delivers a constant-voltage 15V output. Because it is rated at 1W, it is intended for low-power embedded circuits rather than larger 15V loads.

Is the DPRN01L-15 suitable for low-power industrial interface or instrumentation boards?

It can be used where the application needs a regulated 15V output and the load stays within 1W. The listed output current is 0.03A, which aligns with light-duty interface and instrumentation sections.

Would this converter fit compact telecom or IT boards that only have a 5V input rail available?

Yes, it is designed for systems with a 4.75-5.5V input and a modest 15V output requirement. Its 19.6 x 10.14 x 7.1 mm dimensions and 0.0025 kg weight make it suitable for space-constrained board designs.

Can the DPRN01L-15 be used in small automation modules that need 15V for signal-level electronics?

It is a fit for low-power automation electronics that need a constant-voltage 15V output and remain within the 1W limit. This makes it more appropriate for signal and interface circuitry than for high-current devices.

How does the DPRN01L-15 compare with the DPRN01L-12?

Both models are 1W converters in the same series. The DPRN01L-12 is rated at 12V and 0.04A, while the DPRN01L-15 is rated at 15V and 0.03A.

Is the DPRN01L-15 suitable for outdoor locations or high-temperature equipment?

The unit has an operating temperature range of -40°C to +90°C, so it is specified for wide-temperature operation. No IP rating is shown in the provided specs, so the datasheet details here do not indicate outdoor sealing.

Model	Power	Voltage	Current	IP Rating	Price
Mean Well DPRN01O-15 DC-DC Converter - 1W - 45.6~52.8V in ±15V out	1W	15V	0.03A	Indoor	$5.35	View
Mean Well DPRN01O-12 DC-DC Converter - 1W - 45.6~52.8V in ±12V out	1W	12V	0.04A	Indoor	$5.35	View
Mean Well DPRN01N-15 DC-DC Converter - 1W - 22.8~26.4V in ±15V out	1W	15V	0.03A	Indoor	$5.35	View
Mean Well DPRN01N-12 DC-DC Converter - 1W - 22.8~26.4V in ±12V out	1W	12V	0.04A	Indoor	$5.35	View
Mean Well DPRN01M-15 DC-DC Converter - 1W - 11.4~13.2V in ±15V out	1W	15V	0.03A	Indoor	$5.35	View
Mean Well DPRN01M-12 DC-DC Converter - 1W - 11.4~13.2V in ±12V out	1W	12V	0.04A	Indoor	$5.35	View
Mean Well DPRN01L-12 DC-DC Converter - 1W - 4.75~5.5V in ±12V out	1W	12V	0.04A	Indoor	$5.35	View
