Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well DPRN01N-12 DC-DC Converter - 1W - 22.8~26.4V in ±12V out

SKU:

DPRN01N-12

$5.35 USD

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

Description

Features

SIP6 package with industry-standard pinout

Wide operating temperature range -40~+90°C

Comply to BS EN/EN55032 radiated Class B without additional components

Low cost

Protection: Short circuit

1.5KVDC I/O isolation

3 years warranty

General Specification

Voltage accuracy	±3%
Vibration	10~500Hz, 2G 10min./1 cycle, the period for 60 min, each along the X, Y, and Z axes
Cooling	Free-air convection
Short circuit protection	SPRN01: Current limit protection 60 sec. max., DPRN01: 1 sec. max.
Working temperature	-40°C to +90°C
EMC	Compliance to EN55032 class B, EN61000-4-2,3,4,5,6,8
Temp. Coefficient	0.05% / ℃ (0 ~ 71℃)
Dimension (LxWxH) (mm)	19.67.110.14mm
Potting material	UL 94V-0 rated

Specifications

Brand

Mean Well
Series

DPRN Series
Power Rating

1 Watt
Output Voltage

12 Volt
Rated Current

0.04 Ampere
Input Voltage

22.8V~26.4V
No of Output

2
Dimming Control

None
Standards Met

CE,EMC
Operation Mode

Constant Voltage
Operating Temperature

-40°C~90°C
Warranty

3 Year
Length

0.77 in
Width

0.4 in
Height

0.28 in
Weight

0.01 lb

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can I use the DPRN01N-12 in a 24V-class industrial controller that needs a ±12V rail?

Yes, this model is suited to low-power constant-voltage conversion when the source is in the 22-26VAC range. It provides ±12V output at 1W with 0.04A output current, which aligns with small control or interface sections rather than higher-power loads.

Is the DPRN01N-12 a good fit for embedded analog stages in 24V automation equipment?

It can be used where an embedded design needs a compact ±12V rail from a 22-26VAC input. The 1W rating and 0.04A output current make it appropriate for light analog, measurement, or interface circuitry that does not require larger output capacity.

Can this converter be used in low-power PLC interface or sensor-conditioning circuits?

Yes, if the circuit needs a constant-voltage ±12V output and stays within the 1W power limit. Its small 19.6 × 10.14 × 7.1 mm package also supports use in compact PLC or conditioning modules.

Is the DPRN01N-12 suitable for indoor panels or outdoor field exposure?

The provided specs do not list an IP rating, so it should be considered for protected indoor equipment or enclosed assemblies rather than direct outdoor exposure. The stated operating temperature range is -40°C to +90°C.

How does the DPRN01N-12 compare with the DPRN01N-15?

Both are 1W converters in the same DPRN01N series. The DPRN01N-12 has 12V output at 0.04A, while the DPRN01N-15 has 15V output at 0.03A.

Model	Power	Voltage	Current	IP Rating	Price
Mean Well DPRN01O-15 DC-DC Converter - 1W - 45.6~52.8V in ±15V out	1W	15V	0.03A	Indoor	$5.35	View
Mean Well DPRN01O-12 DC-DC Converter - 1W - 45.6~52.8V in ±12V out	1W	12V	0.04A	Indoor	$5.35	View
Mean Well DPRN01N-15 DC-DC Converter - 1W - 22.8~26.4V in ±15V out	1W	15V	0.03A	Indoor	$5.35	View
Mean Well DPRN01M-15 DC-DC Converter - 1W - 11.4~13.2V in ±15V out	1W	15V	0.03A	Indoor	$5.35	View
Mean Well DPRN01M-12 DC-DC Converter - 1W - 11.4~13.2V in ±12V out	1W	12V	0.04A	Indoor	$5.35	View
Mean Well DPRN01L-15 DC-DC Converter - 1W - 4.75~5.5V in ±15V out	1W	15V	0.03A	Indoor	$5.35	View
Mean Well DPRN01L-12 DC-DC Converter - 1W - 4.75~5.5V in ±12V out	1W	12V	0.04A	Indoor	$5.35	View
