Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well DPRN01N-15 DC-DC Converter - 1W - 22.8~26.4V in ±15V out

SKU:

DPRN01N-15

$5.35 USD

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

Description

Features

SIP6 package with industry-standard pinout

Wide operating temperature range -40~+90°C

Comply to BS EN/EN55032 radiated Class B without additional components

Low cost

Protection: Short circuit

1.5KVDC I/O isolation

3 years warranty

General Specification

Voltage accuracy	±3%
Vibration	10~500Hz, 2G 10min./1 cycle, the period for 60 min, each along the X, Y, and Z axes
Cooling	Free-air convection
Short circuit protection	SPRN01: Current limit protection 60 sec. max., DPRN01: 1 sec. max.
Working temperature	-40°C to +90°C
EMC	Compliance to EN55032 class B, EN61000-4-2,3,4,5,6,8
Temp. Coefficient	0.05% / ℃ (0 ~ 71℃)
Dimension (LxWxH) (mm)	19.67.110.14mm
Potting material	UL 94V-0 rated

Specifications

Brand

Mean Well
Series

DPRN Series
Power Rating

1 Watt
Output Voltage

15 Volt
Rated Current

0.03 Ampere
Input Voltage

22.8V~26.4V
No of Output

2
Dimming Control

None
Standards Met

CE,EMC
Operation Mode

Constant Voltage
Operating Temperature

-40°C~90°C
Warranty

3 Year
Length

0.77 in
Width

0.4 in
Height

0.28 in
Weight

0.01 lb

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can I use the DPRN01N-15 to create a ±15V rail from a 24V-class source in industrial electronics?

Yes, this converter is designed for low-power constant-voltage use when the available input is in the 22-26VAC range. It provides ±15V output at 1W with 0.03A output current, so it fits small analog, control, or interface sections.

Is the DPRN01N-15 suitable for embedded measurement or signal-processing boards?

It can be a fit when the board needs a compact ±15V rail and the total load stays within 1W. The module measures 19.6 × 10.14 × 7.1 mm, which helps in embedded layouts where space is limited.

Can this model be used in low-power automation or instrumentation modules?

Yes, if the module requires a constant-voltage ±15V output and is fed from 22-26VAC. With 0.03A output current and 1W power, it is intended for lighter-duty circuitry rather than larger downstream loads.

Can the DPRN01N-15 be used in outdoor equipment?

The provided specifications do not include an IP rating, so it should be installed inside protected equipment instead of used as an exposed outdoor component. Its operating temperature range is -40°C to +90°C.

What is the difference between the DPRN01N-15 and DPRN01N-12?

These sibling models share the same 1W series format. The DPRN01N-15 delivers 15V output at 0.03A, while the DPRN01N-12 delivers 12V output at 0.04A.

Model	Power	Voltage	Current	IP Rating	Price
Mean Well DPRN01O-15 DC-DC Converter - 1W - 45.6~52.8V in ±15V out	1W	15V	0.03A	Indoor	$5.35	View
Mean Well DPRN01O-12 DC-DC Converter - 1W - 45.6~52.8V in ±12V out	1W	12V	0.04A	Indoor	$5.35	View
Mean Well DPRN01N-12 DC-DC Converter - 1W - 22.8~26.4V in ±12V out	1W	12V	0.04A	Indoor	$5.35	View
Mean Well DPRN01M-15 DC-DC Converter - 1W - 11.4~13.2V in ±15V out	1W	15V	0.03A	Indoor	$5.35	View
Mean Well DPRN01M-12 DC-DC Converter - 1W - 11.4~13.2V in ±12V out	1W	12V	0.04A	Indoor	$5.35	View
Mean Well DPRN01L-15 DC-DC Converter - 1W - 4.75~5.5V in ±15V out	1W	15V	0.03A	Indoor	$5.35	View
Mean Well DPRN01L-12 DC-DC Converter - 1W - 4.75~5.5V in ±12V out	1W	12V	0.04A	Indoor	$5.35	View
