Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well DPRN01M-12 DC-DC Converter - 1W - 11.4~13.2V in ±12V out

SKU:

DPRN01M-12

$5.35 USD

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

Description

Features

SIP6 package with industry-standard pinout

Wide operating temperature range -40~+90°C

Comply to BS EN/EN55032 radiated Class B without additional components

Low cost

Protection: Short circuit

1.5KVDC I/O isolation

3 years warranty

General Specification

Voltage accuracy	±3%
Vibration	10~500Hz, 2G 10min./1 cycle, the period for 60 min, each along the X, Y, and Z axes
Cooling	Free-air convection
Short circuit protection	SPRN01: Current limit protection 60 sec. max., DPRN01: 1 sec. max.
Working temperature	-40°C to +90°C
EMC	Compliance to EN55032 class B, EN61000-4-2,3,4,5,6,8
Temp. Coefficient	0.05% / ℃ (0 ~ 71℃)
Dimension (LxWxH) (mm)	19.67.110.14mm
Potting material	UL 94V-0 rated

Specifications

Brand

Mean Well
Series

DPRN Series
Power Rating

1 Watt
Output Voltage

12 Volt
Rated Current

0.04 Ampere
Input Voltage

11.4V~13.2V
No of Output

2
Dimming Control

None
Standards Met

CE,EMC
Operation Mode

Constant Voltage
Operating Temperature

-40°C~90°C
Warranty

3 Year
Length

0.77 in
Width

0.4 in
Height

0.28 in
Weight

0.01 lb

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can I use the DPRN01M-12 in a 12V nominal embedded or automation system that needs a regulated 12V output?

It is designed for a listed input range of 11.4-13.2V and provides a constant-voltage 12V output. With 1W total power, it is intended for low-power electronics rather than larger 12V loads.

Is the DPRN01M-12 suitable for low-power control, sensing, or interface circuits on a 12V bus?

Yes, it fits applications that already operate in the 11.4-13.2V input range and only need a small regulated 12V rail. The rated output current is 0.04A, so it is best for light-duty control and interface functions.

Would this converter work in compact industrial or embedded boards with limited space?

It is well suited to compact boards because the package measures 19.6 x 10.14 x 7.1 mm and weighs 0.0025 kg. The converter delivers constant-voltage 12V output with a 1W power rating.

Can the DPRN01M-12 be used in mobile or vehicle-adjacent electronics that operate around 12V nominal input?

It is intended for systems that stay within the listed 11.4-13.2V input range and need a 12V constant-voltage output. The 1W rating makes it suitable for low-power electronics only.

What is the difference between the DPRN01M-12 and DPRN01M-15?

Both are 1W models in the DPRN01M series. The DPRN01M-12 provides 12V at 0.04A, while the DPRN01M-15 provides 15V at 0.03A.

Is the DPRN01M-12 suitable for outdoor or wide-temperature environments?

Its operating temperature range is -40°C to +90°C, which supports use across a broad temperature range. No IP rating is listed in the provided specifications, so outdoor protection is not identified here.

Model	Power	Voltage	Current	IP Rating	Price
Mean Well DPRN01O-15 DC-DC Converter - 1W - 45.6~52.8V in ±15V out	1W	15V	0.03A	Indoor	$5.35	View
Mean Well DPRN01O-12 DC-DC Converter - 1W - 45.6~52.8V in ±12V out	1W	12V	0.04A	Indoor	$5.35	View
Mean Well DPRN01N-15 DC-DC Converter - 1W - 22.8~26.4V in ±15V out	1W	15V	0.03A	Indoor	$5.35	View
Mean Well DPRN01N-12 DC-DC Converter - 1W - 22.8~26.4V in ±12V out	1W	12V	0.04A	Indoor	$5.35	View
Mean Well DPRN01M-15 DC-DC Converter - 1W - 11.4~13.2V in ±15V out	1W	15V	0.03A	Indoor	$5.35	View
Mean Well DPRN01L-15 DC-DC Converter - 1W - 4.75~5.5V in ±15V out	1W	15V	0.03A	Indoor	$5.35	View
Mean Well DPRN01L-12 DC-DC Converter - 1W - 4.75~5.5V in ±12V out	1W	12V	0.04A	Indoor	$5.35	View
