Mean Well DPRN01M-15 DC-DC Converter - 1W - 11.4~13.2V in ±15V out
The DPRN01M is a 1W Mean Well power converter (input range: 4.75~5.5Vdc).
Key Features
- ✓ Input voltage range: 4.75~5.5Vdc
- ✓ 1.5KVDC reinforced I/O isolation
- ✓ Protections: Short circuit
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesDPRN Series
-
Power Rating1 Watt
-
Output Voltage15 Volt
-
Rated Current0.03 Ampere
-
Input Voltage11.4V~13.2V
-
No of Output2
-
Dimming ControlNone
-
Standards MetCE,EMC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length0.77 in
-
Width0.4 in
-
Height0.28 in
-
Weight0.01 lb
::specification::
Frequently Asked Questions
Can I use the DPRN01M-15 to generate a ±15V rail inside a 12V-class industrial control board?
Yes, this model is intended for low-power constant-voltage conversion when the available input is in the 11-13VAC range. Its output is ±15V at 1W with 0.03A output current, so it fits light-duty control, signal, or interface sections rather than higher-load power sections.
Is the DPRN01M-15 suitable for low-power analog circuitry in embedded or automation equipment?
It can be a fit for embedded or automation designs that need a small ±15V constant-voltage rail and stay within the 1W rating. The compact 19.6 × 10.14 × 7.1 mm size also makes it easier to place on dense boards or in space-limited assemblies.
Can I use this converter in a compact instrumentation or signal-conditioning module?
Yes, if the module needs a low-power ±15V output and the source feeding it is 11-13VAC. With 1W total power and 0.03A output current, it is best matched to small instrumentation or conditioning stages instead of heavier control loads.
Is the DPRN01M-15 meant for outdoor or harsh exposed environments?
No IP rating is listed in the provided specs, so it should be treated as a board-level component for use inside a protected enclosure rather than as an exposed outdoor unit. Its operating temperature range is -40°C to +90°C, which supports a wide temperature envelope once it is installed in suitable equipment.
What is the difference between the DPRN01M-15 and DPRN01M-12?
Both models are 1W DC-DC converters in the same series. The DPRN01M-15 provides 15V output at 0.03A, while the DPRN01M-12 provides 12V output at 0.04A.
