Mean Well DPRN01N-15 DC-DC Converter - 1W - 22.8~26.4V in ±15V out
The DPRN01N is a 1W Mean Well power converter (input range: 4.75~5.5Vdc).
Key Features
- ✓ Input voltage range: 4.75~5.5Vdc
- ✓ 1.5KVDC reinforced I/O isolation
- ✓ Protections: Short circuit
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesDPRN Series
-
Power Rating1 Watt
-
Output Voltage15 Volt
-
Rated Current0.03 Ampere
-
Input Voltage22.8V~26.4V
-
No of Output2
-
Dimming ControlNone
-
Standards MetCE,EMC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length0.77 in
-
Width0.4 in
-
Height0.28 in
-
Weight0.01 lb
::specification::
Frequently Asked Questions
Can I use the DPRN01N-15 to create a ±15V rail from a 24V-class source in industrial electronics?
Yes, this converter is designed for low-power constant-voltage use when the available input is in the 22-26VAC range. It provides ±15V output at 1W with 0.03A output current, so it fits small analog, control, or interface sections.
Is the DPRN01N-15 suitable for embedded measurement or signal-processing boards?
It can be a fit when the board needs a compact ±15V rail and the total load stays within 1W. The module measures 19.6 × 10.14 × 7.1 mm, which helps in embedded layouts where space is limited.
Can this model be used in low-power automation or instrumentation modules?
Yes, if the module requires a constant-voltage ±15V output and is fed from 22-26VAC. With 0.03A output current and 1W power, it is intended for lighter-duty circuitry rather than larger downstream loads.
Can the DPRN01N-15 be used in outdoor equipment?
The provided specifications do not include an IP rating, so it should be installed inside protected equipment instead of used as an exposed outdoor component. Its operating temperature range is -40°C to +90°C.
What is the difference between the DPRN01N-15 and DPRN01N-12?
These sibling models share the same 1W series format. The DPRN01N-15 delivers 15V output at 0.03A, while the DPRN01N-12 delivers 12V output at 0.04A.
