Mean Well GP25B13A-R1B Power Supply 50W 5V 12V -5V
The GP25B13A is a 25W Mean Well power converter (input range: 90~264VAC).
Key Features
- ✓ Input voltage range: 90~264VAC
- ✓ Protections: Overload / Over voltage
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesGP Series
-
Power Rating28.5 Watt
-
Output Voltage5 Volt
-
Rated Current2.5 Ampere
-
Input Voltage90V~264V
-
No of Output3
-
Dimming ControlNone
-
Standards MetCB,CE,EAC,FCC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~70°C
-
Warranty3 Year
-
Length4.23 in
-
Width2.64 in
-
Height1.42 in
-
Weight0.66 lb
::specification::
Frequently Asked Questions
Can I use the GP25B13A-R1B in a compact control system that needs 5V logic and ±5V/12V support rails?
Yes, this model's output configuration includes 5V, 12V, and -5V rails, which can suit compact control or interface electronics with mixed-voltage requirements. It is rated for 28.5W total output, with 2.5A available on the 5V rail.
Is this power supply suitable for embedded electronics that combine 5V processors with -5V legacy circuitry?
It can be a fit where a design needs a 5V rail and also uses 12V and -5V outputs in the same low-power system. The unit operates in constant-voltage mode, accepts 90-264VAC input, and is rated for 28.5W total.
Would the GP25B13A-R1B work for industrial interface boards with 5V digital sections?
Yes, it is appropriate for small industrial or automation interface boards that need a regulated 5V supply and additional 12V and -5V rails. The 5V output is rated at 2.5A, so the load on that rail should stay within that current rating.
Can this model be used in low-power measurement or monitoring equipment with multiple DC rails?
It is suitable for low-power electronics that require the specific 5V, 12V, and -5V output combination. The available power is 28.5W total, which makes it better matched to compact instrumentation than to higher-load systems.
Is the GP25B13A-R1B rated for indoor or outdoor environments?
The provided specs list an operating temperature range of -20°C to +70°C, but they do not include an IP rating. Based on the listed data, temperature capability is defined, while outdoor ingress protection is not.
