Mean Well MPS-120-5 Power Supply 110W 5V he rated current is based ...
MEAN WELL MPS-120 Series Power Supplies are 120W singlel output medical type power supplies with 3 years warranty.
Key Features
- ✓Universal AC/Full range
- ✓Low leakage current<180uA
- ✓Protections:Shortzircuit/Overload/Over voltage
- ✓UL60601-1 medical safety approved
- ✓With power good and fail signal outputOptional)
- ✓100% full load burn in test
- ✓Fixed switching frequency at 45KHz
- ✓3 years warranty
-
BrandMean Well
-
SeriesMPS Series
-
Power Rating110 Watt
-
Output Voltage5 Volt
-
Rated Current22 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~70°C
-
Warranty3 Year
-
Length7 in
-
Width4.25 in
-
Height1.4 in
-
Weight1.21 lb
::specification::
Frequently Asked Questions
Can I use the MPS-120-5 for a 5V PLC accessory or industrial logic load?
Yes, it supplies a constant 5V output up to 22A, with 110W total power. That makes it suitable for 5V industrial logic assemblies, controller accessories, and other 5V DC loads that need higher current capacity.
Is this power supply appropriate for 5V embedded computing or single-board systems?
It can be a fit for 5V embedded systems when the total demand stays within 22A and 110W. The constant-voltage design is intended for loads that require a fixed 5V DC source rather than a constant-current output.
Can the MPS-120-5 support a bank of 5V automation electronics in one enclosure?
Yes, its 22A output capacity is useful where several 5V automation or control loads share one power source. The 90-264VAC input range also supports operation across common global AC input ranges.
Is the MPS-120-5 suitable for harsh indoor or outdoor conditions?
The provided specifications give an operating temperature range of -20°C to +70°C, but they do not list an IP rating. That supports temperature evaluation, but it does not confirm suitability for outdoor, wet, or dust-exposed environments.
How does this compare with the other 5V MPS power supplies?
The listed 5V models are MPS-30-5 at 25W and 5A, MPS-45-5 at 40W and 8A, MPS-65-5 at 60W and 12A, MPS-120-5 at 110W and 22A, and MPS-200-5 at 200W and 40A. This version sits above the 65W model and below the 200W model for 5V output capacity.
