Mean Well MPS-120-48 Power Supply 120W 48V he rated current is base...
MEAN WELL MPS-120 Series Power Supplies are 120W singlel output medical type power supplies with 3 years warranty.
Key Features
- ✓Universal AC/Full range
- ✓Low leakage current<180uA
- ✓Protections:Shortzircuit/Overload/Over voltage
- ✓UL60601-1 medical safety approved
- ✓With power good and fail signal outputOptional)
- ✓100% full load burn in test
- ✓Fixed switching frequency at 45KHz
- ✓3 years warranty
-
BrandMean Well
-
SeriesMPS Series
-
Power Rating120 Watt
-
Output Voltage48 Volt
-
Rated Current2.5 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~70°C
-
Warranty3 Year
-
Length7 in
-
Width4.25 in
-
Height1.4 in
-
Weight1.21 lb
::specification::
Frequently Asked Questions
Can I use the MPS-120-48 for 48V industrial sensors or control devices?
Yes, it provides a constant 48V output up to 2.5A, with 120W total capacity. It is suited to 48V industrial or automation equipment that requires a fixed 48V DC source and stays within those limits.
Is this a good fit for 48V telecom or network hardware that needs DC power?
It can be used for 48V DC equipment when the load does not exceed 2.5A or 120W. Buyers should match the equipment's required voltage exactly to 48V, since this is a constant-voltage model.
Can the MPS-120-48 power a 48V automation subsystem inside a machine enclosure?
Yes, the 48V constant-voltage output and 120W rating make it appropriate for enclosed automation subsystems that run on 48V DC. Its input range of 90-264VAC also supports operation from a wide AC mains range.
Is this power supply intended for outdoor use?
The listed operating temperature is -20°C to +70°C, but no IP rating is provided in the specs. Based on the supplied data, temperature capability is defined, while exposure to rain, dust, or hose-down conditions is not.
What are the 48V options in the MPS series and where does this model fit?
The 48V siblings listed are MPS-30-48 at 28.8W and 0.6A, MPS-45-48 at 48W and 1A, MPS-65-48 at 64.8W and 1.35A, MPS-120-48 at 120W and 2.5A, and MPS-200-48 at 200W and 4.2A. This model is the mid-to-upper option among the 48V versions.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other MPS-120 Models
5 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well MPS-120-5 Power Supply 110W 5V he rated current is based on there being a fan that can provide 25CFM. | 110W | 5V | 22A | Indoor | $95.98 | View |
| Mean Well MPS-120-3.3 Power Supply 79W 3.3V he rated current is based on there being a fan that can provide 25CFM. | 79.2W | 3.3V | 24A | Indoor | $95.98 | View |
| Mean Well MPS-120-24 Power Supply 120W 24V he rated current is based on there being a fan that can provide 25CFM. | 120W | 24V | 5A | Indoor | $95.98 | View |
| Mean Well MPS-120-15 Power Supply 120W 15V he rated current is based on there being a fan that can provide 25CFM. | 120W | 15V | 8A | Indoor | $95.98 | View |
| Mean Well MPS-120-12 Power Supply 120W 12V he rated current is based on there being a fan that can provide 25CFM. | 120W | 12V | 10A | Indoor | $95.98 | View |
