Mean Well HBG-60-1050 Power Supply 60W 2100mA
The HBG-60 is a 60W Mean Well power converter.
Key Features
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Protections: Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHBG Series
-
Power Rating60.9 Watt
-
Output Voltage35 Volt
-
Rated Current2.1 Ampere
-
Input Voltage90V~295V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Current
-
Operating Temperature-40°C~85°C
-
Warranty5 Year
-
Length4.33 in
-
Width4.33 in
-
Height2.38 in
-
Weight1.1 lb
::specification::
Frequently Asked Questions
Can I use the HBG-60-2100 for LED downlights that need higher current and lower forward voltage?
Yes, if the LED downlight is designed for constant current operation and its load voltage falls within the 19-29V constant current range. This model provides 60.9W, so it is aimed at higher-current LED loads in a lower voltage band. It is not a constant voltage power supply.
Is the HBG-60-2100 appropriate for a small high-current LED array?
It can be appropriate for a small LED array when the array is built for constant current operation and its forward voltage stays within 19-29V. With 60.9W output, it is oriented toward higher-current arrays rather than higher-voltage strings. The electrical match should be based on constant current requirements, not only nominal voltage.
Can this driver be used for compact signage modules that run at lower forward voltage?
It can fit compact signage modules if they are constant current modules and the total LED forward voltage is within 19-29V. The driver's 60.9W rating sets the power ceiling for the assembly. It is not intended for constant voltage signage systems.
How do I check LED compatibility for the HBG-60-2100?
The LED load needs to be a constant current load with a total forward voltage in the 19-29V constant current range. The number of LEDs depends on each LED's forward voltage, so there is no single stated LED count for this model. The total power also has to remain within 60.9W.
What is the difference between the HBG-60-2100 and the lower-current HBG-60 versions?
The HBG-60-2100 is the lower-voltage, higher-current version at 60.9W with a 19-29V CC range and 2.1mA output. By comparison, the HBG-60-1400 is 60.2W with a 28-43V CC range at 1.4mA, and the HBG-60-1050 is 57.75W with a 37-55V CC range at 1.05mA. The P versions listed for these models keep the same electrical specifications.
What environmental conditions are covered by the HBG-60-2100 specs?
The operating temperature range is -40°C to +85°C. Those numbers define thermal operating conditions, but the provided specs do not include an IP rating. That means water and dust exposure suitability is not defined in the data shown here.
