Mean Well SCWN06B-12 DC-DC Converter - 6W 18~36V DC in 12V out
The SCWN06B is a 6W Mean Well power converter (input range: 9~18Vdc, operating temperature: -40~+100℃).
Key Features
- ✓ Input voltage range: 9~18Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+100℃
- ✓ Protections: Short circuit / Overload / Under voltage
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSCWN Series
-
Power Rating6 Watt
-
Output Voltage12 Volt
-
Rated Current0.5 Ampere
-
Input Voltage18V~36V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length1.25 in
-
Width0.8 in
-
Height0.4 in
-
Weight0.03 lb
::specification::
Frequently Asked Questions
Can I use the SCWN06B-12 to power a 12V sensor or small industrial transmitter from a 18-36V bus?
Yes, this model is a constant-voltage DC-DC converter with 18-36V input and 12V output. Its 6W rating and 0.5A output current make it suitable for low-power 12V sensors, transmitters, or interface devices that stay within those limits.
Is the SCWN06B-12 suitable for embedded 12V control electronics in compact equipment?
It is a fit for embedded 12V electronics when the load needs regulated 12V and draws no more than 0.5A. The compact 31.8 × 20.3 × 10.2 mm size and 0.0125 kg weight also make it practical where board or enclosure space is limited.
Can this converter be used for a small 12V relay or actuator control circuit?
It can be used for a 12V control circuit if the total load stays within 6W and 0.5A output. This makes it better suited to light-duty control electronics than to higher-current 12V loads.
What is the difference between the SCWN06B-12 and the other SCWN06B models?
All SCWN06B models in this group are 6W converters with 18-36V input, but they differ in output. The SCWN06B-03 provides 3.3V at 1.2A, the SCWN06B-05 provides 5V at 1A, the SCWN06B-12 provides 12V at 0.5A, and the SCWN06B-15 provides 15V at 0.4A.
Is the SCWN06B-12 suitable for outdoor or high-temperature environments?
The operating temperature range is -40°C to +90°C, which supports use in demanding temperature conditions. No IP rating is listed in the provided specs, so the specs do not establish suitability for direct outdoor, wet, or dust-exposed use without added protection.
