Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well SCWN06B-15 DC-DC Converter - 6W 18~36V DC in 15V out 400mA
The SCWN06B is a 6W Mean Well power converter (input range: 9~18Vdc, operating temperature: -40~+100℃).
Key Features
- ✓ Input voltage range: 9~18Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+100℃
- ✓ Protections: Short circuit / Overload / Under voltage
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSCWN Series
-
Power Rating6 Watt
-
Output Voltage15 Volt
-
Rated Current0.4 Ampere
-
Input Voltage18V~36V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length1.25 in
-
Width0.8 in
-
Height0.4 in
-
Weight0.03 lb
::specification::
Frequently Asked Questions
Can I use the SCWN06B-15 for a 15V industrial control or measurement circuit?
Yes, this converter is intended for regulated 15V output from a 18-36V input range. With 6W capacity and 0.4A output current, it fits low-power 15V control, measurement, or interface circuits that stay within those limits.
Is the SCWN06B-15 a good fit for embedded 15V electronics inside compact automation equipment?
It is suitable where the embedded circuit requires constant 15V and no more than 0.4A. The 31.8 × 20.3 × 10.2 mm package and 0.0125 kg weight are useful for small enclosure layouts.
Can this model power a small 15V analog or instrumentation module from a 24V nominal source?
It can, as long as the source stays within the 18-36V input range and the load stays within 6W and 0.4A at 15V output. That makes it appropriate for low-power 15V analog or instrumentation modules rather than heavier 15V loads.
How does the SCWN06B-15 compare with other SCWN06B output options?
The SCWN06B-15 is the 15V version of the 6W, 18-36V input family. The sibling outputs are 3.3V at 1.2A on SCWN06B-03, 5V at 1A on SCWN06B-05, and 12V at 0.5A on SCWN06B-12, while this model provides 15V at 0.4A.
Can the SCWN06B-15 be used in harsh temperature conditions or outdoor equipment?
This unit is rated for operation from -40°C to +90°C, so the temperature range supports demanding indoor equipment environments. No IP rating is provided in the listed specs, so exposure resistance for outdoor or washdown conditions is not established here.
