Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well SCWN06C-15 DC-DC Converter - 6W 36~72V DC in 15V out
The SCWN06C is a 6W Mean Well power converter (input range: 9~18Vdc, operating temperature: -40~+100℃).
Key Features
- ✓ Input voltage range: 9~18Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+100℃
- ✓ Protections: Short circuit / Overload / Under voltage
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSCWN Series
-
Power Rating6 Watt
-
Output Voltage15 Volt
-
Rated Current0.4 Ampere
-
Input Voltage36V~72V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length1.25 in
-
Width0.8 in
-
Height0.4 in
-
Weight0.03 lb
::specification::
Frequently Asked Questions
Can I use the SCWN06C-15 to generate 15V power inside industrial control equipment?
Yes, this model is intended for constant-voltage conversion where a 15V output is needed from a 36-72V input source. Its 6W rating and 0.4A output make it better suited to lower-power industrial control, embedded, or monitoring circuits than higher-current 15V loads.
Is the SCWN06C-15 suitable for embedded electronics that run on a higher-voltage DC bus?
It can fit embedded designs that need a regulated 15V rail from a 36-72V input range. The available output is 15V at 0.4A, so it is appropriate when the embedded load stays within the 6W output capacity.
Can this converter be used for low-power automation or sensing circuits that need 15V?
Yes, the constant-voltage 15V output is a match for low-power automation electronics that operate from a higher-voltage source in the 36-72V range. The key sizing limit is the 0.4A maximum output current and 6W power rating.
How does the SCWN06C-15 compare with the other SCWN06C models?
Within the 6W SCWN06C series, the SCWN06C-03 provides 3.3V at 1.2A, the SCWN06C-05 provides 5V at 1A, the SCWN06C-12 provides 12V at 0.5A, and the SCWN06C-15 provides 15V at 0.4A. All of these listed siblings are 6W models, so the main difference is the output voltage and current combination.
Is the SCWN06C-15 suitable for outdoor or harsh-temperature use?
This page lists an operating temperature range of -40°C to +90°C, which is broad for temperature exposure. However, no IP rating is provided here, so the product data does not indicate outdoor weather protection or sealed-enclosure performance.
