Mean Well ODLV-45A-12 Power Supply 45W 12V (Auxiliary DC output)
The ODLV-45A is a 45W Mean Well DIN rail power converter with a 111mm profile (input range: 90~295VAC, operating temperature: -40~+80℃).
Key Features
- ✓ 111mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 90~295VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+80℃
- ✓ Protections: Short circuit
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: (type”HL”) UL8750 BIS IS15885( for ODLV-45-12,24,48 only), EAC TP TC 004,IP67
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesODLV Series
-
Power Rating36 Watt
-
Output Voltage12 Volt
-
Rated Current3 Ampere
-
Input Voltage90V~295V
-
No of Output1
-
Dimming Control0-10V,10V PWM,Auxiliary DC Output
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~85°C
-
Warranty3 Year
-
Length4.37 in
-
Width3.03 in
-
Height1.12 in
-
Weight0.93 lb
::specification::
Frequently Asked Questions
Can I use the ODLV-45A-12 for 12V LED strip lights?
Yes, if the strip is a 12V constant-voltage type and the total connected load stays within 36W. This model outputs 12V DC at up to 3A, so it fits 12V strip lighting within that power limit.
Is the ODLV-45A-12 suitable for 12V sign lighting?
It can be used for 12V constant-voltage signage and light box loads up to 36W. The IP67 rating also supports use where the driver needs protection from rain or wet conditions.
Can this model power outdoor 12V accent or landscape lighting?
Yes, for 12V constant-voltage outdoor lighting applications that stay within the 36W rating. Its IP67 enclosure and -20°C to +85°C operating range make it suitable for exposed and temperature-variable locations.
How do I size LED strip length for the ODLV-45A-12?
The calculation is maximum length = 36W divided by the strip's watts per meter. Since this driver is rated for 36W total at 12V, check your strip rated power per meter before estimating the usable run length.
How does the ODLV-45A-12 compare with other ODLV 12V and higher-voltage models?
The listed siblings include 12V 36W 3A, 24V 45.12W 1.88A, 36V 45W 1.25A, 48V 45.12W 0.94A, and 60V 45W 0.75A in both standard ODLV-45 and ODLV-45A variants. Higher-output options in the same family are 12V 50.4W 4.2A, 24V 57.6W 2.4A, 36V 64.8W 1.8A, 48V 64.8W 1.35A, and 60V 64.8W 1.08A, also with matching A versions.
