Mean Well PLD-25-1050 Power Supply 25W 1050mA
The PLD-25 is a 25W Mean Well power converter (input range: 40~58V, operating temperature: -30~+60℃).
Key Features
- ✓ Input voltage range: 40~58V
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~+60℃
- ✓ Protections: Short circuit / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: UL8750, CSA C22.2 No. 250.0-08(except for PLD-25-350, PLD-25-700), ENEC EN 61347-1, EN 61347-2-13 independent, EN 62384, IP42
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesPLD Series
-
Power Rating25.2 Watt
-
Output Voltage24 Volt
-
Rated Current1.05 Ampere
-
Input Voltage90V~295V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,cUL,EAC,ENEC,FCC
-
Operation ModeConstant Current
-
Operating Temperature-30°C~60°C
-
Warranty3 Year
-
Length3.31 in
-
Width2.24 in
-
Height1.16 in
-
Weight0.42 lb
::specification::
Frequently Asked Questions
Can I use the PLD-25-1050 for a 1050mA LED downlight?
Yes, if the downlight is built for 1050mA constant current and the LED load operates within the 16-24V constant current range. This model provides up to 25.2W, giving it more headroom than the 16.8W PLD-16 versions at similar voltage ranges. It is meant for constant current LED loads, not constant voltage fixtures.
Is the PLD-25-1050 suitable for brighter small LED arrays?
Yes, it can support small LED arrays that require 1050mA constant current and have a total forward voltage between 16V and 24V. The exact LED count depends on the forward voltage of each LED. Its 25.2W rating makes it a stronger fit for higher-power compact arrays than a 16.8W unit.
Can this model be used for compact signage modules that need constant current?
It can be used for signage modules only if they are designed for 1050mA constant current operation and fall within the 16-24V CC range. If the signage system expects constant voltage, this driver is not appropriate. The output mode here is constant current only.
How do I check LED compatibility with the PLD-25-1050?
Look for an LED load that requires 1050mA constant current and whose operating range fits inside 16-24V on the output. The number of LEDs depends on each LED's forward voltage, so there is no single fixed LED quantity. The load should also stay within the 25.2W power rating.
What conditions is the PLD-25-1050 designed to handle?
This driver is rated IP42, so it is intended for protected environments rather than direct exposure to rain or washdown. Its operating temperature range is -30°C to +60°C. That higher +60°C limit gives it a wider temperature envelope than the PLD-16 models listed here.
