Mean Well UHP-750-48 Power Supply 753.6W 48V
The UHP-750 is a 750W Mean Well power converter (input range: 12~14.4V, operating temperature: -30~+70℃).
Key Features
- ✓ Input voltage range: 12~14.4V
- ✓ DC output voltage adjustable ±10%
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Cooling by free air convection
- ✓ Wide operating temperature: -30~+70℃
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ DC OK relay contact output
- ✓ Safety approvals: UL62368-1,TUV EN62368-1, EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesUHP Series
-
Power Rating753.6 Watt
-
Output Voltage48 Volt
-
Rated Current15.7 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Standards MetCB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length9.33 in
-
Width3.94 in
-
Height1.61 in
-
Weight3.09 lb
::specification::
Frequently Asked Questions
Can I use the Mean Well UHP-750-48 for a 48V industrial automation system?
Yes, this model is a 48V constant voltage power supply rated for 753.6W and 15.7A, which fits 48V industrial automation equipment that needs a regulated DC output. Its slim low-profile form factor, fanless design, and 90-264VAC input also make it suitable for control panels and automation cabinets where space and airflow are limited.
Is the UHP-750-48 suitable for 48V embedded or industrial IT equipment?
It can be a fit for embedded or industrial IT systems that require a 48V constant voltage source and draw within 15.7A or 753.6W. The fanless design helps in quieter enclosed equipment, and the 90-264VAC input supports use across common AC mains ranges.
Can this power supply run a 48V system with a higher continuous load?
It is intended for 48V constant voltage loads up to 15.7A and 753.6W. If your system needs more than that, this model is undersized and you would need a higher-capacity option in the same series.
Is the Mean Well UHP-750-48 good for indoor or outdoor use?
The provided specs list an operating temperature range of -30°C to +70°C, so it is designed to handle a wide temperature range. However, no IP rating is listed in the provided specs, so outdoor or exposed-environment suitability is not established from this data alone.
How does the UHP-750-48 compare with the other UHP-750 models?
Within the UHP-750 range, the UHP-750-12 is 720W at 12V and 60A, the UHP-750-24 is 751.2W at 24V and 31.3A, the UHP-750-36 is 752.4W at 36V and 20.9A, and the UHP-750-48 is 753.6W at 48V and 15.7A. The main difference across these models is the output voltage and current combination, while all are in the same general power class.
