Mean Well ELG-200-C1750D2 AC-DC Single output LED Driver (CC) with PFC
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well ELG-200-C1750D2 AC-DC Single output LED Driver (CC) with PFC
The ELG-200 is a 200W Mean Well power converter (input range: 100~305VAC).
Key Features
- ✓ Input voltage range: 100~305VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: (type”HL”), CSA C22.2 No. 250.13-12;IEC/EN/AS/NZS 61347-1, IEC/EN/AS/NZS 61347-2-13 UL8750 EAC TP TC 004;BIS IS15885(for 12/12B/24/24B/36/36A/42A/48/48A/54A only) GB19510.14,GB19510.1; IP65 or IP67; KC61347 1 KC61347 2 13
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesELG Series
-
Power Rating200 Watt
-
Output Voltage114 Volt
-
Rated Current1.75 Ampere
-
Input Voltage100V~305V
-
No of Output1
-
Dimming Control1-10V
-
Standards MetBSMI,CB,CE,EAC,UL
-
Operation ModeConstant Current
-
Operating Temperature-40°C~85°C
-
Warranty5 Year
-
Length9.61 in
-
Width2.8 in
-
Height1.48 in
-
Weight2.69 lb
::specification::
Frequently Asked Questions
Does the ELG-200-C1750D2 support 0–10V dimming?
Yes. The D2 suffix designates compatibility with both 0–10V analog and PWM dimming signals, allowing integration with standard building management systems and dimming controllers that use these interfaces.
Can the ELG-200-C1750D2 be used to drive LED arrays in commercial office or retail lighting with dimming control?
Yes. At 200W constant current and 1750mA with 0–10V/PWM dimming, this driver is suited for dimmable LED panel lights, linear luminaires, or LED downlights used in office or retail environments where energy-saving dimming schedules are employed.
Is the ELG-200-C1750D2 rated for outdoor or waterproof installations?
Yes. It carries an IP67 waterproof rating and an operating temperature range of -40°C to +85°C, making it deployable in outdoor LED fixtures, wet-location luminaires, and installations exposed to rain or condensation.
What is the maximum output voltage of the ELG-200-C1750D2, and how does it affect LED string sizing?
The ELG-200-C1750D2 has a maximum output voltage of 114V and a CC voltage range of 57–114V. LED strings must have a combined forward voltage within this range to operate at the rated 1750mA; the number of LEDs depends on each LED's individual forward voltage.
How does the ELG-200-C1750D2 compare to the ELG-200-C1750DA?
The D2 variant uses analog 0–10V and PWM dimming interfaces common in most lighting control systems. The DA variant uses DALI protocol for digital, addressable control suited to smart building systems. Both are 200W at 1750mA; the D2 has a max voltage of 114V while the DA is rated at 120V max.
Can the ELG-200-C1750D2 be used in industrial wash-down or food-processing environments?
Yes. The IP67 waterproof rating allows installation in environments subject to high-pressure cleaning or heavy moisture exposure, such as food-processing facilities, cold storage, and industrial wash-down areas that use LED area or task lighting.
