Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well ELG-200-C2100D2 AC-DC Single output LED Driver (CC) with PFC
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well ELG-200-C2100D2 AC-DC Single output LED Driver (CC) with PFC
The ELG-200 is a 200W Mean Well power converter (input range: 100~305VAC).
Key Features
- ✓ Input voltage range: 100~305VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: (type”HL”), CSA C22.2 No. 250.13-12;IEC/EN/AS/NZS 61347-1, IEC/EN/AS/NZS 61347-2-13 UL8750 EAC TP TC 004;BIS IS15885(for 12/12B/24/24B/36/36A/42A/48/48A/54A only) GB19510.14,GB19510.1; IP65 or IP67; KC61347 1 KC61347 2 13
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesELG Series
-
Power Rating200 Watt
-
Output Voltage96 Volt
-
Rated Current2.1 Ampere
-
Input Voltage100V~305V
-
No of Output1
-
Dimming Control1-10V
-
Standards MetBSMI,CB,CE,EAC,UL
-
Operation ModeConstant Current
-
Operating Temperature-40°C~85°C
-
Warranty5 Year
-
Length9.61 in
-
Width2.8 in
-
Height1.48 in
-
Weight2.69 lb
::specification::
Frequently Asked Questions
Can the ELG-200-C2100D2 be connected to a DALI-2 lighting control network?
Yes. The D2 suffix indicates this model supports the DALI-2 dimming protocol, which is compatible with DALI-2 certified controllers, sensors, and building automation systems. It allows centralized, addressable dimming control of the connected LED load at up to 200W constant current output.
Is the ELG-200-C2100D2 appropriate for LED downlights in a commercial office with DALI automation?
Yes. The DALI-2 interface on the ELG-200-C2100D2 enables integration with occupancy sensors, daylight harvesting controllers, and building management systems. The driver operates at constant current with a CC voltage range of 48–96V, which suits the LED arrays used in commercial downlight fixtures.
Can this driver power LED arrays in outdoor luminaires?
Yes. The ELG-200-C2100D2 is rated IP67, making it suitable for outdoor luminaires exposed to rain, dust, and condensation. Its operating temperature range of -40°C to +85°C and wide 100–305VAC input accommodate a range of outdoor installation conditions.
How does the CC voltage range of the ELG-200-C2100D2 constrain LED string design?
The ELG-200-C2100D2 outputs constant current across a voltage range of 48–96V. LED strings in series must have a combined forward voltage within this range; the driver will regulate the current constant while the output voltage self-adjusts. LEDs with different forward voltages will yield different maximum string lengths.
Does the ELG-200-C2100D2 carry the same certifications as others in this series?
The ELG-200-C2100D2 is certified to BSMI, CB, CE, EAC, and UL. This set covers Taiwan (BSMI), North America (UL), the EU (CE), and Russia/Eurasia (EAC). Note that the D2 variant does not carry the CCC, ENEC, c_bsi, or c_rcm certifications held by other variants in this series.
Can the ELG-200-C2100D2 be used for LED lighting in a freezer storage facility?
Yes. The -40°C lower operating temperature limit and IP67 waterproof rating make the ELG-200-C2100D2 suitable for freezer and cold-storage lighting. The sealed metal enclosure withstands both the low temperatures and condensation typical of these environments.
