Description
Description
Features
4"x2" compact size |
Universal AC input / Full range |
Built-in active PFC function |
EMI Conduction for Class B Radiation for Class B with FG(Class I ) and ( Class A without FG(Class II) No load power consumption<0.5W High efficiency up to 94% |
Protections: Short circuit/Overload/Over voltage/Over temperature |
Cooling by free air convection for 140W and 200W with 10CFM forced air |
Built-in 12V /0.5A FAN supply |
LED indicator for power on |
Operating altitude up to 5000 meters |
3 years warranty |
General Specification
AC input voltage range | 80~264VAC; 113~370VDC |
AC inrush current | COLD START 30A/115VAC |
Leakage current | <0.75mA / 240VAC |
Overload protection | 110 ~ 140% rated output power |
Over-voltage protection | 110%~130% rated output voltage |
Setup, rise, hold up time | 500ms, 30ms, 12ms |
Withstand voltage | I/P-O/P:3KVAC, I/P-FG:2KVAC, O/P-FG:0.5KVAC |
Working temperature | -30~+70°C |
Vibration | 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes |
Safety standards | UL62368-1, TUV BS EN/EN62368-1, IEC62368-1, EAC TP TC 004 approved |
EMC standards | UL62368-1, TUV BS EN/EN62368-1, EAC TP TC 004 approved |
Connection | I/P: 3 Pin JST B3P-VH, O/P: 4 Pin JST B4P-VH |
Dimension (LxWxH) | 101.6x50.8x29 |
Packing | 72pcs / 14.7kg |
Specifications
Specifications
-
BrandMean Well
-
SeriesEPP Series
-
Power Rating141.6 Watt
-
Output Voltage24 Volt
-
Rated Current5.9 Ampere
-
Input Voltage80V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length4 in
-
Width2 in
-
Height1.14 in
-
Weight0.42 lb
