Mean Well EPP-400-18 Power Supply 250W 18V
Description
Description
Features
| Universal AC input / Full range |
| Built-in active PFC function EMI Class B for Class I & Class A for Class II configuration |
| High efficiency up to 93% |
| Withstand 300VAC surge input for 6 seconds No load power consumption<0.5W by PS ON control 5"x3" miniature size High efficiency up to 94% |
| Protections: Short circuit/Overload/Over voltage/Over temperature |
| Cooling by free air convection for 250W and 400W with 25 CFM forced air Built-in 12V/0.5A FAN With power good and fail signal output Built-in remote sense function |
No load power consumption under 0.5W by PS-ON control |
| LED indicator for power on Output 18V available |
| Operating altitude up to 5000 meters |
| 3 years warranty |
General Specification
| AC input voltage range | 80 ~ 264VAC; 113 ~ 370VDC |
| AC inrush current | COLD START 40A/115VAC |
| Leakage current | <0.75mA / 240VAC |
| Overload protection | 105 ~ 135% rated output power |
| Over-voltage protection | 108%~130% rated output voltage |
| Setup, rise, hold up time | 1000ms, 30ms, 16ms |
| Withstand voltage | I/P-O/P:3KVAC, I/P-FG:2KVAC, O/P-FG:0.5KVAC |
| Working temperature | -30~+70°C |
| Vibration | 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes |
| Safety standards | UL62368-1, TUV BS EN/EN62368-1,BS EN/EN60335-1, IEC62368-1, CCC GB4943.1, EAC TP TC 004 approved |
| EMC standards | UL62368-1, TUV BS EN/EN62368-1, EAC TP TC 004 approved |
| Connection | I/P: 3 Pin JST B3P-VH, O/P: 4 Pin JST B4P-VH |
| Dimension (LxWxH) | 127x76.2x35 |
| Packing | 36pcs / 15kg |
Specifications
Specifications
-
BrandMean Well
-
SeriesEPP Series
-
Power Rating250.5 Watt
-
Output Voltage18 Volt
-
Rated Current13.9 Ampere
-
Input Voltage80V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CCC,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length5 in
-
Width3 in
-
Height1.38 in
-
Weight0.86 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the EPP-400-18 for 18V industrial or embedded equipment?
Yes, if the equipment requires a constant-voltage 18V DC source and the total load stays within 13.9A and 250.5W. It is intended for applications that specifically call for 18V rather than the more common 12V or 24V rails.
Is the EPP-400-18 suitable for 18V production test fixtures or lab setups?
It can be a good fit for test fixtures that need regulated 18V DC with up to 13.9A available. The 80-264VAC input range also helps when the fixture may be used across different AC supply environments.
Can this model power several 18V boards or subsystems from one supply?
Yes, provided all connected loads are 18V constant-voltage devices and their combined demand does not exceed 13.9A or 250.5W. That makes it workable as a centralized 18V source for grouped embedded or industrial subsystems.
Is the EPP-400-18 appropriate for 18V automation accessories or specialty control hardware?
It is appropriate when the accessory or control hardware is specified for 18V DC input and needs no more than 250.5W total. The important fit criteria are the fixed 18V output and the available 13.9A current capacity.
Can the EPP-400-18 be used outside or in difficult thermal conditions?
The thermal rating is -30°C to +70°C, so the product data supports operation across a wide temperature range. No IP rating is listed in the provided specs, so outdoor, dust-tight, or water-resistant use should not be assumed from this information alone.
