Mean Well GC120A12-R7B Portable Chargers 102W 13.6V 7.5A - Green Ad...
Description
Description
Features
| Universal AC input / Full range |
| Built-in active PFC function |
| Protections: Short circuit / Overload / Over voltage / Over Temp. |
| No load power consumption < 0.5W |
| High efficiency up to 91% |
| 2 stage charging characteristic |
| Cooling by free air convection |
| 3 pole AC inlet IEC320-C14 |
| Class I power (with earth pin) |
| Fully enclosed plastic case |
| 2 color LED indicator for charging status |
| 2 years warranty |
General Specification
| AC input voltage range | 85~264VAC; 120~370VDC |
| Overload protection | 90~110% constant current, auto-recovery |
| Over voltage protection | 105%~135% shut down O/P voltage, re-power on to recover |
| Withstand voltage | I/P-O/P: 3kVAC |
| Working temperature | -30~+70°C (refer to derating curve) |
| Safety standards | UL1012 (GC120Axx-AD1 only), EN60950-1 approved |
| EMC standards | EN55022 class B, FCC part 15 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11 |
| Dimension (LxWxH) | 167x 67x 35 mm |
| Length of output cable | 120cm of UL2464, 18AWGx 4C |
| Standard DC plug | Power DIN 4P with lock type (R7B) |
Specifications
Specifications
-
BrandMean Well
-
SeriesGC Series
-
Power Rating102 Watt
-
Output Voltage13.6 Volt
-
Rated Current7.5 Ampere
-
Input Voltage85V~264V
-
No of Output1
-
Standards MetCB,CE,cUL,EAC,FCC,TUV
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty2 Year
-
Length6.57 in
-
Width2.64 in
-
Height1.38 in
-
Weight1.37 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What is the Mean Well GC120A12-R7B designed for?
The GC120A12-R7B is a portable AC-DC charger and power supply rated at 102W. It provides a 13.6V DC output at up to 7.5A, making it suitable for equipment or charging applications that require this output level. Its portable enclosed adaptor-style design is intended for professional and commercial use.
What are the key electrical specifications of the GC120A12-R7B?
This model is rated for 102W output with a nominal output of 13.6V DC and 7.5A. It accepts a universal input range of 85 to 264VAC or 120 to 370VDC. The unit also includes active PFC and can reach efficiency up to 91%.
What type of output connector does the GC120A12-R7B use?
The standard DC plug on this model is a Power DIN 4P with lock type, identified as R7B. That connector style is a defining feature of this specific variant. Buyers should confirm that their equipment matches the R7B locking plug format before ordering.
Can the GC120A12-R7B be used in demanding temperature conditions?
This charger is specified for operation from -30°C to +70°C, subject to the manufacturer's derating guidance. That makes it suitable for a wide range of industrial and field environments. It also uses free air convection cooling, so no internal fan is required.
What protection features are included in the GC120A12-R7B?
The GC120A12-R7B includes protection against short circuit, overload, over voltage, and over temperature. Overload protection operates at 90 to 110% constant current with auto-recovery. Over-voltage protection shuts down the output and requires re-powering to recover.
How does this model compare with a standard fixed-output power adaptor?
Compared with a basic adaptor, the GC120A12-R7B adds features that are useful in professional charging and power applications, including active PFC, a 2-stage charging characteristic, and status indication through a 2-color LED. It also offers a locking Power DIN 4P output plug rather than a generic DC barrel style. These differences make it better suited to applications that need a purpose-built portable charger or industrial-grade power unit.
