Mean Well GC120A24-R7B Portable Chargers 120.2W 27.2V 4.42A - Green...
The GC120A24 is a 120W Mean Well power converter.
Key Features
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload / Over voltage / Over temperature
- ✓ Safety approvals: EN62368-1
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesGC Series
-
Power Rating120.2 Watt
-
Output Voltage27.2 Volt
-
Rated Current4.42 Ampere
-
Input Voltage85V~264V
-
No of Output1
-
Standards MetCB,CE,cUL,EAC,FCC,TUV
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty2 Year
-
Length6.57 in
-
Width2.64 in
-
Height1.38 in
-
Weight1.37 lb
::specification::
Frequently Asked Questions
What are the main output specifications of the Mean Well GC120A24-R7B?
The GC120A24-R7B is rated for 120.2W output with a 27.2V output voltage and 4.42A rated current. It is positioned as a portable charger and power supply in Mean Well's GC120A series.
What type of AC input does this charger support?
This model accepts a universal AC input range of 85 to 264VAC, and it also supports 120 to 370VDC input. That wide input range makes it suitable for use across many standard power environments without needing a region-specific version.
What output connector does the GC120A24-R7B use?
This version uses a Power DIN 4P locking DC plug identified as the R7B type. Buyers should confirm their equipment is designed for the R7B locking plug format before ordering.
Does this model include built-in protection features?
Yes. The GC120A24-R7B includes protection for short circuit, overload, over voltage, and over temperature. Its overload protection is specified at 90 to 110% constant current with auto-recovery.
Is the GC120A24-R7B suitable for demanding temperature environments?
This model is rated for operation from -30°C to +70°C, subject to the manufacturer's derating guidance. That gives it a broader operating range than many indoor-only commercial power adapters.
What makes this model a good fit for portable industrial or commercial use?
It combines a fully enclosed plastic case, free-air convection cooling, active PFC, and low no-load power consumption below 0.5W. The compact 167 x 67 x 35 mm size and 0.62 kg weight also help when portability and space efficiency matter.
What compliance and approval information is listed for this charger?
The product is listed with EN60950-1 safety approval, and the EMC specifications include EN55022 Class B, FCC Part 15 Class B, and multiple EN61000 immunity and harmonic standards. UL1012 is noted only for GC120Axx-AD1 variants, so buyers should not assume that approval applies to the R7B version.
